神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (01-066[02]) - HARNESS ASSY HAND CONTROL, N&B Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
570 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN11E00040F1 | [1] | HARNESS | KOBHARNESS ASSY HAND CONTROL, N&B |
| . . | YN11E00040F2 | [1] | WIRE HARNESS | KOBHARNESS ASSY HAND CONTROL ROT N&B |
| . . | YN11E00040F3 | [1] | HARNESS | KOBHARNESS ASSY HAND CONTROL ROTATING |
| . . | YN11E00040F4 | [1] | HARNESS | KOBHARNESS ASSY HAND CONTROL BREAKER |
| 1. | YN11E01111P1 | [1] | HARNESS | KOBHARNESS,INSIDE CAB ,FOR F1,F2,&F3ONLY |
| 2. | EN24S00008P1 | [2] | RELAY | KOBFOR F1&F3 ONLY (5 Spade Relay) |
| . . | EN24S00008P1 | [4] | RELAY | KOBFOR F2 ONLY (5 Spade Relay) |
| 3. | ZM61C06016 | [2] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher), FOR F1&F3 Only |
| . . | ZM61C06016 | [4] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher), FOR F2 Only |
| 4. | YB03M01003F2 | [1] | GRIP | KOBAssembly, Left Hand |
| 5. | YB03M01003F3 | [1] | GRIP | KOBAssembly, Right Hand |
| 6. | PY01P01043D3 | [5] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long, FOR F1 ONLY |
| . . | PY01P01043D3 | [6] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long, FOR F2&F3 ONLY |
| 7. | YN11E01112P1 | [1] | HARNESS | KOBNIBBLER SOL, FOR F1 & F2ONLY |
| 8. | YN11E01113D1 | [1] | HARNESS | KOBROTATION SOL, FOR F2 & F3 ONLY |
| 9. | YN11E01122P1 | [1] | HARNESS | KOBBREAKER SOL, FOR F4 ONLY |
