凯斯零件查询(FLX4010) - FLOATER (8/04-8/06) (04-006) - REAR AXLE BRAKE, "SERIAL# Y8T024152 AND LATER" Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
972 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 2. |
84175120
|
[45] |
SEAL
|
BN
Camshaft
|
| 3. |
84175112
|
[4] |
BUSHING
|
BN
Camshaft
|
| 4. |
84175130
|
[1] |
BRACKET, SUPPORTING
|
BN
Chamber, LH
|
| 4. |
84175132
|
[1] |
BRACKET, SUPPORTING
|
BN
Chamber, RH
|
| 5. |
84175121
|
[2] |
O-RING
|
BN
Camshaft
|
| 6. |
84175341
|
[2] |
BRAKE ADJUSTER
|
BN
SLACK ADJUSTER, AUTO
|
| 8. |
84175272
|
[2] |
WASHER
|
BN
Camhead Brake
|
| 9. |
84175114
|
[4] |
BUSHING
|
BN
Anchor Pin
|
| 11. |
84175277
|
[4] |
PIN
|
BN
shoe anchor Superseded by part number: BN2451614
|
| 12. |
84175754
|
[2] |
BRAKE SHOE
|
BN
with hardware
|
| 13. |
BN2451943
|
[8] |
SEAL
|
BN
Felt Pin, Brake Shoe
|
| 14. |
87271287
|
[8] |
SNAP RING
|
BN
Brake Pin
|
| 16. |
BN2451945
|
[2] |
SPRING
|
BN
Return, Brake Shoe
|
| 17. |
NSS
|
[2] |
NOT SOLD SEPARAT
|
CON
RETAINER
|
| 19. |
84175361
|
[2] |
PROTECTION PLATE
|
BN
Dust Shield, LH Upper And RH Lower
|
| 20. |
BN2450237
|
[12] |
BOLT
|
BN
Dust Shield S-264-1
|
| 22. |
84175362
|
[2] |
PROTECTION PLATE
|
BN
Dust Shield, RH Upper And LH Lower
|
| 24. |
84175322
|
[4] |
BRAKE SHOE
|
BN
With Lining, Roller
|
| 25. |
84175133
|
[1] |
CAMSHAFT
|
BN
BRAKE, L.H.
|
| 25. |
84175134
|
[1] |
CAMSHAFT
|
BN
BRAKE, R.H. Superseded by part number: 87670779
|
| 27. |
84169494
|
[2] |
CLAMP
|
BN
Brake Chamber
|
| 28. |
87392254
|
[2] |
SPIDER
|
BN
ASSY, BRAKE
|
| 29. |
BN2451806
|
[8] |
RETAINER
|
BN
Pin, Brake Shoe Anchor
|
| 30. |
84175896
|
[2] |
ADJUSTABLE CLEVIS
|
BN
CHAMBER AXLE (ADJ. SLACKER)
|
| 31. |
87267993
|
[2] |
RING
|
BN
Snap, Camshaft
|
| 32. |
84175929
|
[2] |
SET SCREW
|
BN
HH
|
| 33. |
84181338
|
[2] |
WASHER
|
BN
Shim
|
| 34. |
84181334
|
[2] |
WASHER
|
BN
Inner Slack Adjustment
|
| 35. |
84190221
|
[6] |
WASHER
|
BN
|
