神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (01-068[03]) - HARNESS ASSY, ENGINE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
262 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM16E00006F1 | [1] | HARNESS | KOBHARNESS ASSY, ENGINE |
| 1. | YM16E01009P2 | [1] | HARNESS | KOB |
| 2. | YN16E01018P1 | [1] | BRACKET | KOB |
| 3. | 2432R233D1 | [2] | CLIP | KOB37x12x40mm |
| 4. | PY01P01043D3 | [4] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 5. | 2432R233D3 | [3] | CLIP | KOB50x16x60mm |
| 6. | ZN18C10008 | [1] | NUT | KOBM10x1.50mm |
| 7. | ZW26X10000 | [1] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 8. | ZM22C08025 | [2] | BOLT | KOBM08x1.25x25mm (Incls. Washer & Lockwasher) |
| 10. | ZS18C06045 | [1] | CAP,Hex, M6 x 45mm | KOBScrew -- M06x1.0x45mm |
| 11. | ZW26X06000 | [2] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 12. | ZW16X10000 | [2] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 13. | ZW26X08000 | [1] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 14. | YM16E01008P1 | [1] | PLATE | KOBPLATE |
| 16. | ZS18C08016 | [1] | SCREW,Hex, M8 x 16mm | KOBM08x1.25x16mm |
| 17. | ZS18C06010 | [1] | SCREW,Hex, M6 x 10mm | KOBM06x1.0x10mm |
| 18. | ZW16X06000 | [1] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 19. | ZS18C05010 | [1] | SCREW,Hex, M5 x 10mm | KOBM05x0.8x10mm |
| 20. | ZW26X05000 | [1] | LOCK WASHER | KOBLock -- ID 05 x OD 09 x Th 1.3mm |
