神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (35.310.AA[02]) - HYD. LINE, UPPER (BASE) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
350 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ZX30H12140 | [1] | HOSE,Hyd, 19mm ID x 31.20mm OD x 140mm L | KOB(72205236) |
| 2. | ZX30H12145 | [2] | HOSE | KOB(72205237) |
| 3. | YB03H01118P1 | [2] | HYD CONNECTOR | KOB(87577235) |
| 4. | YB03H01076D6 | [1] | HYDRAULIC HOSE,15.88mm ID x 600mm L | KOB(87570523) |
| 5. | YB03H01076D2 | [2] | HYDRAULIC HOSE | KOB(87338438) |
| 6. | ZX30H12150 | [1] | HOSE | KOB(72203664) |
| 7. | YB03H01076D5 | [1] | HYDRAULIC HOSE | KOB(87570519) |
| 8. | YB03H01076D7 | [1] | HYDRAULIC HOSE | KOB(87570518) |
| 9. | YM03H01066P1 | [1] | TUBE | KOB(87338554) |
| 10. | YM03H01067P1 | [1] | TUBE | KOB(87338556) |
| 11. | YB03H01092P1 | [1] | SUPPORT ASSY. | KOB(87338449) |
| 12. | YW03H01183P1 | [1] | CLAMP | KOB(72204101) |
| 13. | ZG23F12012 | [4] | HYD CONNECTOR | KOB(71404414) |
| 14. | HH25R12012G4 | [1] | HYD CONNECTOR | KOB(72214712) |
| 15. | HG24F10012G4 | [1] | HYD CONNECTOR | KOB(72206168) |
| 16. | ZS18C12035 | [2] | SCREW,Hex, M12 x 35mm | KOB(11112634) |
| 17. | ZS18C10065 | [5] | SCREW,Hex, M10 x 65mm | KOB(11107534) |
| 18. | ZS18C12030 | [4] | SCREW,Hex, M12 x 30mm | KOB(11112434) M12x1.75x30mm |
| 19. | ZD12A01600 | [12] | O-RING | KOB(71484462) |
| 20. | ZD12A01800 | [6] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOB(70923843) |
| 21. | YB03H01076D8 | [1] | HYDRAULIC HOSE | KOB(87570526) |
| 22. | ZW16H10000 | [5] | WASHER | KOB(14496631) |
| 23. | ZW16H12000 | [7] | WASHER | KOB(14496731) ID 13 x OD 26 x Th 3.2mm |
| 24. | YN03H01075P1 | [2] | BUSHING,21mm ID x 39mm OD x 50mm L | KOB(72204102) |
| 25. | YB03H01075P1 | [1] | SUPPORT ASSY. | KOB(87338456) |
| 26. | YN03H01427P1 | [2] | CLAMP | KOB(72204618) |
| 27. | YN03H01431P1 | [4] | BUSHING,28mm ID x 56mm OD x 70mm L | KOB(72204608) |
| 28. | ZG23F10012 | [2] | HYD CONNECTOR | KOB(72206233) |
| 29. | HG23H10012G1 | [2] | HYD CONNECTOR | KOB(72206231) |
| 30. | HG24F10012G3 | [3] | HYD CONNECTOR | KOB(72217410) |
| 31. | YB03H01117P1 | [1] | BRACKET | KOB(71473983) |
| 32. | ZS18C12055 | [1] | SCREW,Hex, M12 x 55mm | KOB(11113334) |
| 33. | YB03H01123P1 | [1] | BRACKET | KOBBracket Assy (87574089) Superseded by part number: 87574089 |
