神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (35.310.AG[01]) - HYD. LINE, RETURN Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
629 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87386095 | [1] | FLEXIBLE HOSE | SM(YB32H01023P1) |
| 2. | 87338505 | [1] | FLEXIBLE HOSE | SM(YB32H01035P1) |
| 3. | 87386093 | [2] | U-BOLT | SM(YB32H01026P1) |
| 4. | 11112434 | [4] | BOLT,Hex, M12 x 30mm, Cl 10.9, Full Thd | LEC(ZS18C12030) Superseded by part number: 11112431 |
| 5. | 11112634 | [4] | SCREW | IMO(ZS18C12035) Superseded by part number: 626-12035 |
| 6. | 14496731 | [10] | WASHER,M12 x 24 x 2.5 Thk | LEC(ZW16H12000) Superseded by part number: 895-11012 |
| 7. | 70924192 | [3] | O-RING | LEC(ZD12P03800) Superseded by part number: 14464080 |
| 8. | 16100821 | [8] | NUT,M8, Cl 10 | LEC(ZN18C08007) Superseded by part number: 17037925 |
| 9. | 87386094 | [2] | PLATE | SM(YB32H01024P1) |
| 10. | 14496531 | [4] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC(ZW16H08000) Superseded by part number: 86624184 |
