神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (35.310.AG[04]) - HYD. LINE, BOOM Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
658 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YM42HU1004P1 | [1] | TUBE,4211.4, 3129.8 mm L | KOB |
| 2. | YM42HU1005P1 | [1] | TUBE,4210.7, 3129.8 mm L | KOB |
| 3. | YM42HU1002P1 | [1] | TUBE | KOB |
| 4. | YM42HU1003P1 | [1] | TUBE | KOB |
| 5. | ZD12A01800 | [6] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOB |
| 6. | ZM73C12035 | [14] | BOLT,M12x35mm - Course Thread | KOB |
| 7. | YN42H02348P1 | [4] | CLAMP | KOB |
| 8. | YN42H02351P1 | [6] | CLAMP | KOB Superseded by part number: 84528894 |
| 9. | YN42H02349P1 | [2] | CLAMP | KOB |
| 10. | YN42H02319P1 | [7] | BUSHING,27.2mm ID x 34mm OD x 83mm L | SM Superseded by part number: 84354627 |
| 11. | YN43H01524P1 | [2] | BUSHING,34mm ID x 53mm OD x 83mm L | KOB Superseded by part number: 84354629 |
| 12. | YN42H02355P1 | [4] | CLAMP | KOB Superseded by part number: 84528898 |
