神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (35.353.AD[05]) - TRAVEL MOTOR & REDUCTION GEAR, ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
622 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN15V00051F4 | [2] | HYDRAULIC MOTOR | KOBPropel, Incl 2 - 46 |
| 1. | YN15V00051F5 | [2] | HYDRAULIC MOTOR | KOBPropel, Incl 2 - 46 |
| 2. | LQ15V00019R200 | [1] | REPAIR KIT | KOBIncl 28, 32 Superseded by part number: LQ15V00031R200 |
| 3. | YN15V00051R400 | [1] | REPAIR KIT | KOBIncl 34 |
| 4. | LQ15V00020R600 | [1] | BLOCK | KOBRepair Kit, Incl 35, 36, 37, 38 |
| 5. | LQ15V00007R700 | [1] | REPAIR KIT | KOBIncl 43 |
| 6. | LQ15V00007R800 | [1] | REPAIR KIT | KOBIncl 44 |
| 7. | LQ15V00031R920 | [1] | REPAIR KIT | KOBIncl 16, 17, 18, 24, 26, 33, 42, 43, 44, 45 |
| 8. | LQ15V00031R930 | [1] | REPAIR KIT | KOBIncl 45, 46 |
| 9. | LQ15V00007S082 | [8] | SCREW | KOBCap |
| 10. | LQ15V00007S083 | [4] | PLATE | KOB |
| 11. | LQ15V00007S084 | [4] | RACE | KOBInner |
| 12. | LQ15V00020S076 | [4] | NEEDLE BEARING | SMNeedle |
| 13. | LQ15V00007S086 | [4] | DRIVEN GEAR | KOB |
| 14. | LQ15V00020S078 | [4] | PLATE | SM |
| 15. | LQ15V00007S088 | [4] | SCREW | KOBCap |
| 16. | LQ15V00020S080 | [1] | GEAR | SMSun |
| 17. | LQ15V00007S090 | [1] | RING | KOB |
| 18. | LQ15V00020S082 | [1] | CARRIER | SM |
| 19. | LQ15V00007S092 | [3] | PLATE | KOB |
| 20. | LQ15V00020S084 | [3] | RACE | SMInner |
| 21. | LQ15V00020S085 | [3] | NEEDLE BEARING | SMNeedle |
| 22. | LQ15V00020S086 | [3] | GEAR | SM |
| 23. | LQ15V00007S096 | [3] | PLATE | KOB |
| 24. | LQ15V00020S088 | [1] | PLATE | SM |
| 25. | LQ15V00007S098 | [3] | SCREW | KOBCap |
| 26. | LQ15V00020S090 | [1] | GEAR | SM |
| 27. | LQ15V00007S103 | [3] | PLUG | KOB |
| 28. | ZD12P02400 | [3] | O-RING | KOB |
| 29. | LQ15V00007S105 | [4] | PIN | KOB |
| 30. | LQ15V00007S060 | [3] | PLATE | KOB |
| 31. | LQ15V00020S053 | [1] | PISTON | SM |
| 32. | LQ15V00031S061 | [2] | SEAL | KOB |
| 33. | NSS | [1] | NOT SOLD SEPARAT | CONFlange, Incl in 7 |
| 34. | NSS | [1] | NOT SOLD SEPARAT | CONPlate, Incl in 3 |
| 35. | NSS | [1] | NOT SOLD SEPARAT | CONBlock, Incl in 4 |
| 36. | NSS | [9] | NOT SOLD SEPARAT | CONPiston ASSY., Incl in 5 |
| 37. | NSS | [1] | NOT SOLD SEPARAT | CONPlate, Incl in 6 |
| 38. | NSS | [1] | NOT SOLD SEPARAT | CONHolder, Incl in 7 |
| 39. | NSS | [2] | NOT SOLD SEPARAT | CONPiston ASSY., Incl in 1 |
| 40. | NSS | [1] | NOT SOLD SEPARAT | CONPlug, Incl in 1 |
| 41. | NSS | [1] | NOT SOLD SEPARAT | CONPlug, Incl in 1 |
| 42. | NSS | [1] | NOT SOLD SEPARAT | CONHousing, Incl in 7 |
| 43. | NSS | [1] | NOT SOLD SEPARAT | CONShim, Incl in 5 or 7 |
| 44. | NSS | [1] | NOT SOLD SEPARAT | CONPlate, Incl in 6 or 7 |
| 45. | NSS | [1] | NOT SOLD SEPARAT | CONCover, Incl in 7 or 8 |
| 46. | NSS | [16] | NOT SOLD SEPARAT | CONCapscrew, Incl in 8 |
