神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (35.737.AA) - ARM, CYLINDER, ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
473 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | LQ01V00013S003 | [1] | BASE PLATE | KOB |
| 2. | 2438U999S4 | [1] | BUSHING | KOB |
| 3. | 2438U999S5 | [1] | RING | KOB |
| 4. | YM01V00017S006 | [1] | RING | KOB |
| 5. | YM01V00017S007 | [1] | RING | KOB |
| 6. | 2438U999S8 | [1] | RING | KOB |
| 7. | 2438U1135S35 | [1] | RING | KOB |
| 8. | ZD12G12000 | [1] | O-RING,3.1mm Thk x 119.4mm ID, 90 Duro | KOB |
| 9. | 2438U1102S12 | [1] | O-RING | KOB |
| 10. | ZS23C16075 | [12] | SCREW,Hex Socket Head, M16 x 75mm | KOB |
| 11. | YM01V00008S013 | [1] | BEARING | KOB |
| 12. | LQ01V00005S014 | [1] | SEAL | KOB |
| 13. | LQ01V00030S014 | [1] | PISTON | KOB |
| 14. | 2438U675S20 | [1] | RING | KOB |
| 15. | YM01V00008S017 | [2] | RING | KOB |
| 16. | LQ01V00030S017 | [2] | RING | KOB |
| 17. | 2438U675S28 | [2] | RING | KOB |
| 18. | 2438U999S21 | [1] | SET SCREW | KOB |
| 19. | 2436U330S16 | [1] | BALL | KOB |
| 20. | 2438U1948S24 | [1] | BEARING | KOB |
| 21. | LQ01V00007S025 | [1] | SEAL | KOB |
| 22. | 2438U1104S25 | [2] | STOP | KOB |
| 23. | 2438U1948S27 | [1] | RING | KOB |
| 24. | YM01V01011P1 | [4] | BUSHING,80mm ID x 90mm OD x 54.5mm L | KOB |
| 25. | 2438U1102S31 | [4] | SEAL | KOB |
| 26. | YM01V00017R100 | [1] | REPAIR KIT | KOBKit, Repair Rod Side Contains Items 4X1, 5X1, 6X1, 7X1, 8X1, 9X1 |
| 27. | LQ01V00030R200 | [1] | REPAIR KIT | KOBPiston Side Contains Items 14X1, 15X2, 16X2, 17X2 |
| 28. | YM01V00017R300 | [1] | REPAIR KIT | KOBAll (Rod & Piston) Contains Items 4X1, 5X1, 6X1, 7X1, 8X1, 9X1, 14X1, 15X2, 16X2, 17X2 |
| 29. | YM01V00017R400 | [1] | REPAIR KIT | KOBKit, Repair Contains Items tube(not serviced), 24X2, 25X2 |
| 30. | YM01V00017R500 | [1] | REPAIR KIT | KOBKit, Repair Contains Items rod(not serviced), 24X2, 25X2 |
