神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (39.101.AC) - FRAME, ASSY, UPPER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
617 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YB52F00094P1 | [1] | FRAME | KOBSchematic, Center Section |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONDeck, L/H, NSS, Part of YM52F00064P1 |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONDeck Assy, R/H, NSS, Part of YM52F00064P1 |
| 4. | LQ52F01737P1 | [1] | FRAME | KOB |
| 5. | NSS | [1] | NOT SOLD SEPARAT | CONPlate, NSS, Part of YM52F00064P1 |
| 6. | NSS | [1] | NOT SOLD SEPARAT | CONPlate, NSS, Part of YM52F00064P1 |
| 7. | 87357461 | [1] | BRACKET | KOBBracket Assy (YN52F01916P1) Superseded by part number: YN52F01916P1 |
| 8. | NSS | [1] | NOT SOLD SEPARAT | CONPlate, NSS, Part of YM52F00064P1 |
| 9. | NSS | [1] | NOT SOLD SEPARAT | CONBracket, NSS, Part of YM52F00064P1 |
| 10. | 87640500 | [1] | PLATE | KOBPlate (YM52F01147P1) |
