卡特零件查询（735） 153-1116: MOUNTING GP-ENGINE
广数供应链运营团队, 15 02月, 2025，浏览：
992 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 6Y-9980 | [2] | MOUNT AS | |
| | 9W-8095 | [1] | PAD-REBOUND | |
| | 9W-9958 | [1] | MOUNT | |
| 2. | 9W-6582 | [2] | SLEEVE | |
| 3. | 9W-6584 | [2] | WASHER(20.5X114X10-MM THK) | |
| 4. | 9W-7385 | [2] | SLEEVE | |
| 5. | 9W-7388 | [2] | WASHER(26X144X12-MM THK) | |
| 6. | 9W-9930 | [2] | MOUNT AS | |
| 7. | 190-5271 | [1] | BRACKET(LH) | |
| 8. | 190-5272 | [1] | BRACKET(RH) | |
| 9. | 7X-2555M | [12] | BOLT(M16X2X80-MM) | |
| 10. | 8C-8478M | [2] | BOLT(M20X2.5X140-MM) | |
| 11. | 8T-1482 | [2] | WASHER-HARD(26X50X8-MM THK) | |
| 12. | 8T-4123 | [4] | WASHER(3.62X5.75X0.375-MM THK) | |
| 13. | 8T-4131M | [2] | NUT(M20X2.5-THD) | |
| 14. | 8T-6380M | [2] | BOLT(M24X3X130-MM) | |
| 15. | 9X-8257 | [12] | WASHER(17.5X30X3.5-MM THK) | |
| | M | | METRIC PART |
