卡特零件查询（735） 176-5745: PISTON & ROD GP
广数供应链运营团队, 15 02月, 2025，浏览：
204 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 221-2305 | [1] | CROWN AS-PISTON | |
| 2. | 132-6663 | [1] | SKIRT-PISTON | |
| 3. | 168-7246 | [1] | PIN-PISTON | |
| 4. | 7E-1177 | [2] | RETAINER-PIN | |
| 5. | 9Y-6054 | [1] | ROD AS-CONNECTING | |
| 5A. | 7E-4195M | [2] | BOLT-CONNECTING ROD(M16X1.5X97-MM) | |
| 5B. | 7N-2043 | [2] | DOWEL | |
| 5C. | 4P-7377 | [1] | BUSHING | |
| 6. | 328-5573 | [1] | BEARING-CONNECTING ROD(STANDARD) | |
| | 7E-0558AB | | BEARING-CONNECTING ROD(0.635-MM US) | |
| | 7E-0559AB | | BEARING-CONNECTING ROD(1.27-MM US) | |
| 7. | 134-3761 | [1] | RING-PISTON(TOP) | |
| 8. | 176-5749 | [1] | RING-PISTON(INTERMEDIATE) | |
| 9. | 189-9771 | [1] | RING-PISTON(OIL CONTROL) | |
| 10. | 277-3076 | [1] | TUBE AS-OIL JET | |
| 11. | 151-5925 | [1] | BOLT(7/16-14-THD) | |
| | A | | NOT PART OF THIS GROUP |
| | B | | USE AS REQUIRED |
| | M | | METRIC PART |
| | R | | REMANUFACTURED PART MAY BE AVAILABLE |
