神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (55.101.AC[01]) - HARNESS, ASSY, UPPER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
579 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YM13E01032P1 | [1] | WIRE HARNESS | SMAssembly |
| 2. | 87571059 | [1] | ELECTRIC CABLE | SM Superseded by part number: 84553222 |
| 3. | 71450316 | [1] | ELECTRIC CABLE | LECBattery Superseded by part number: 84553148 |
| 4. | 71450318 | [1] | ELECTRIC CABLE | LEC Superseded by part number: 84553205 |
| 5. | 71450342 | [1] | ELECTRIC CABLE | SMEngine GRD Superseded by part number: 84553443 |
| 6. | 87526680 | [7] | RETAINER COLLAR | SM Superseded by part number: YN13E01375P1 |
| 7. | 14496531 | [5] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC Superseded by part number: 86624184 |
| 8. | 16043231 | [4] | SCREW,Hex, M8 x 16mm, Cl 10.9, Full Thd | LEC |
| 9. | 14496731 | [7] | WASHER,M12 x 24 x 2.5 Thk | LEC Superseded by part number: 895-11012 |
| 10. | 11112134 | [7] | SCREW | BRE Superseded by part number: 11112131 |
| 11. | 72951499 | [45] | CLIP | IMO Superseded by part number: PY01P01043D8 |
| 12. | 14496631 | [2] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | LEC Superseded by part number: 14496621 |
| 13. | 11701721 | [1] | NUT,M10, Cl 10 | LEC Superseded by part number: 17038131 |
| 14. | 11106034 | [1] | BOLT,Hex, M10 x 20, 10.9, Full Thd | BUR Superseded by part number: 11106031 |
| 15. | 87571058 | [1] | ELECTRIC CABLE | SMStarter Superseded by part number: 47515690 |
