神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (55.101.AC[07]) - HARNESS, CAB Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
968 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | LB14E01006P1 | [1] | WIRE HARNESS | SMCab |
| 2. | PY01P01043D3 | [26] | CABLE TIE,188mm L | KOB |
| 3. | YN13E01375P1 | [12] | CLIP,M8 x 8.20mm Shank | KOB |
| 4. | YT11E01043P1 | [4] | SPRING | SM |
| 5. | ZM73C06016 | [1] | BOLT,M6x16mm - Course Thread | KOBSems |
| 6. | YN11E01205P1 | [1] | WIRE HARNESS | KOBHour Meter, Pre SB K000-60-002 |
| 6. | YN11E01296P1 | [1] | WIRE HARNESS | KOBHour Meter, Post SB K000-60-002 |
| 6. | YN58S00012P1 | [1] | HOURMETER | KOBKit, Incl Hourmeter & Harness, See SB K000-60-002 |
| 7. | YN13E01580P1 | [1] | WIRE HARNESS | KOBPower Supply Socket |
| 8. | PY01P01043D5 | [1] | CABLE TIE,301mm L | KOB |
