神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (55.404.DB[02]) - FLASHER LAMP Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
869 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| .. | YM80S00001F1 | [1] | LAMP | KOBLeft Lamp Assembly |
| .. | YM80S00001F2 | [1] | LAMP | KOBRight Lamp Assembly |
| 1. | YN80S00015S001 | [4] | BULB | KOB Superseded by part number: 2456U85S4 |
| 2. | YN80S00015S004 | [1] | LENS | KOBLeft |
| 2. | YN80S00015S005 | [1] | LENS | KOBRight |
| 3. | YN80S00015S006 | [1] | LENS | KOBLeft |
| 3. | YN80S00015S007 | [1] | LENS | KOBRight |
| 4. | YN80S00015S009 | [1] | GASKET | KOB |
| 5. | YN80S00015S010 | [2] | SCREW | KOB |
| 6. | YN80S00015S011 | [4] | SCREW | KOB |
| 7. | YN80S00015S012 | [1] | BODY | KOBLeft |
| 7. | YN80S00015S013 | [1] | BODY | KOBRight |
| 8. | YM80S00001S014 | [1] | CABLE | KOB |
