神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (55.512.AA[02]) - RADIO Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
820 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN03M02108F3 | [1] | COVER ASSY | KOB |
| 2. | YN54S00069P1 | [1] | RADIO,AM/FM/WB/AUX/BT/USB | KOB |
| 3. | YN17M01072P1 | [1] | CABLE | KOB Superseded by part number: 72203961 |
| 4. | PY01P01043D8 | [9] | CABLE TIE,102mm L | KOB |
| 5. | ZM66C06016 | [2] | BOLT | KOB |
| 6. | YN54E01043P1 | [1] | CAGE | KOB Superseded by part number: 84485553 |
| 7. | LB13E01058P1 | [1] | HARNESS | KOB |
| 8. | LB13E01056P1 | [1] | WIRE HARNESS | SM |
| 9. | YN54E01033P1 | [1] | BRACKET | SM |
| 10. | 14304134 | [4] | SCREW,M5 x 12mm | IMO(ZM66C05012) |
