神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (55.530.AB) - BRACKET MONITOR EQUIPMENT (REAR VIEW CAMERA) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
1028 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN55S00009F1 | [1] | VIDEO CAMERA | KOB |
| 2. | LC55E01008P1 | [1] | COVER | SM Superseded by part number: YN55E01097P1 |
| 3. | LC55E01006P1 | [1] | BRACKET | KOB |
| 4. | YN21C03253D4 | [1] | GASKET | SM |
| 5. | 11112234 | [2] | BOLT,Hex, M12 x 25mm, Cl 10.9, Full Thd | LEC(ZW73C12025) Superseded by part number: 11112231 |
| 6. | 16043231 | [2] | SCREW,Hex, M8 x 16mm, Cl 10.9, Full Thd | LEC(ZS18C08016 or ZW73C08016) |
| 7. | 14496731 | [2] | WASHER,M12 x 24 x 2.5 Thk | LEC Superseded by part number: 895-11012 |
| 8. | 14496531 | [2] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC(ZW16P08000) Superseded by part number: 86624184 |
