神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (55.640.AG) - CONTROLLER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
815 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| .. | YM22E00041F1 | [1] | CONTROLLER | KOBNot Shown (Programmed) Superseded by part number: YN22E00425F1 |
| .. | YN22E00425F1 | [1] | CONTROLLER | KOBNot Shown (Unprogrammed) |
| 1. | YN22E01322P1 | [1] | SUPPORT | SM |
| 2. | YN22E01363P1 | [1] | SUPPORT | SM |
| 3. | LP22E01016P2 | [1] | SUPPORT | KOB |
| 4. | YX50S00004F1 | [1] | TOGGLE SWITCH | KOB(YN50S00047P1) |
| 5. | 72203539 | [1] | DATA PLAQUE | SM(YN22M01014P1) |
| 6. | YN22E01366P1 | [1] | RETAINER | SM |
| 7. | YN22E01334P1 | [5] | COLLAR | SM |
| 8. | 72950894 | [1] | SOFT TRIM | IMO(PM22C01020D7) Superseded by part number: PM22C01020D7 |
| 9. | 72955941 | [1] | SOFT TRIM | KOB(PM22C01020DH) Superseded by part number: PM22C01020DH |
| 10. | 72952745 | [7] | BOLT | IMO(ZM61C06025) Superseded by part number: ZM61C06025 |
| 11. | 72209121 | [2] | SCREW | IMO(ZM66C06016) Superseded by part number: ZM66C06016 |
| 12. | 11106234 | [2] | BOLT,Hex, M10 x 1.5 x 25 mm, Cl 10.9, Full Thd | BUR(ZS18C08020) Superseded by part number: 11106231 |
| 13. | ZM73C10025 | [4] | BOLT,M10x25mm - Course Thread | KOB |
| 14. | 72956186 | [1] | WASHER | KOB(YN02C02015P1) Superseded by part number: YN02C02015P1 |
| 15. | ZS18C08020 | [2] | SCREW,Hex, M8 x 20mm | KOB |
| 16. | 87588712 | [1] | TOGGLE SWITCH | SM(YX50S00001F1) Superseded by part number: YX50S00004F1 |
| 17. | 72958297 | [1] | LABEL | KOB(YV22E01002P1) Superseded by part number: YV22E01002P1 |
| 18. | 13270417 | [4] | SCREW,Pozidriv Pan Hd, M3 x 8mm, Cl 5.8, Full Thd | SM(ZM41C03008) |
| 19. | 72200773 | [1] | RESISTOR | SM(LC22E01001D1) Superseded by part number: LC22E01001D1 |
| 20. | LP22E01013P1 | [1] | BRACKET | SM |
| 21. | ZM61C04012 | [1] | BOLT | KOB |
