神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (84.100.AD[01]) - QUICK COUPLER, CONTROL BOX ASSY (HENDRIX) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
285 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | - | [1] | Hendrix Quick Coupler Controller | |
| 1. | LC32TU1043P2 | [1] | CONTROLLER | KOB |
| 2. | YN17M01320P1 | [2] | SCREW,Phillips Drive, Truss HD, M6 x 1 x 15mm | SMNot Shown |
| 3. | YN32TU1059P1 | [2] | ELEC CONNECTOR | KOBNot Shown |
| 4. | YN32TU1061P1 | [3] | ELEC CONNECTOR | KOBConnector, Not Shown |
| 5. | PY01P01043D4 | [20] | CABLE TIE,4.80mm W x 251mm L | KOBNot Shown |
| 6. | YN32TU1060P1 | [3] | TERMINAL CONNECTOR | KOBNot Shown |
| 7. | YN32T02260P1 | [1] | BRACKET | KOBBracket, Not Shown |
| 8. | YN32TU1062P1 | [3] | POP RIVET | KOBRivet, Pop, Not Shown |
| 9. | YN32TU1012F1 | [1] | LABEL | KOBLabel Assy (Hendrix Coupler); Not Shown; Inc. 10 - 11 |
| 10. | YN32TU1012S001 | [1] | DECAL | KOBLabel; Not Shown |
| 11. | YN32TU1012S002 | [1] | HANDBOOK | KOBManual, Operators; Not Shown |
| 12. | YM32TU1047P1 | [1] | DIAGNOSTIC COUPLER | KOBCoupler, Hendrix; Not Shown |
| 13. | YM02BU0009P1 | [1] | BOOM | KOBBoom Rework; Not Shown; Inc. 14 |
| 14. | YT02B01059P1 | [1] | BLOCK | KOBTapped |
