神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (84.100.AD[06]) - QUICK COUPLER, VALVE (HENDRIX) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
611 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YM42HU1018P1 | [1] | BRACKET | KOBBracket |
| 2. | LC32TU1047P1 | [1] | HYDRAULIC MANIFOLD | KOBManifold Block |
| 3. | LC32TU1045P1 | [1] | SOLENOID VALVE | KOBSolenoid Valve |
| 4. | LC32TU1046P1 | [1] | HARNESS | KOBHarness Assy |
| 5. | ZH32X06000 | [2] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90? -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| 6. | ZH32X04006 | [2] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring | KOB |
| 7. | ZM73C08025 | [2] | BOLT,M8x25mm - Course Thread | KOB |
| 8. | ZS23C06040 | [4] | SCREW,Hex Socket Head, M6 x 40mm | KOB |
| 9. | LC32TU1050P1 | [4] | CAPTIVE WASHER SCREW | KOBCapscrew |
| 10. | PY01P01043D4 | [26] | CABLE TIE,4.80mm W x 251mm L | KOB |
| 11. | ZX25M04340 | [2] | HOSE | KOB |
| 12. | YN32TU1057D8 | [2] | GUARD | KOB |
