神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (84.100.AD[08]) - QUICK COUPLER, ASSY (HENDRIX) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
290 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| .. | YM32TU1047P1 | [1] | DIAGNOSTIC COUPLER | KOBAssy, Incl 1 - 13 |
| 1. | YM32TU1047S001 | [2] | FITTING | KOB |
| 2. | YM32TU1047S002 | [2] | PLATE | KOB |
| 3. | YM32TU1047S003 | [2] | PLATE | KOB |
| 4. | YM32TU1047S004 | [1] | FITTING | KOB |
| 5. | YM32TU1047S005 | [2] | SNAP RING | KOB |
| 6. | YM32TU1047S006 | [1] | FITTING | KOB |
| 7. | YM32TU1047S007 | [2] | SHIM | KOB |
| 8. | YM32TU1047S008 | [1] | PIN | KOB |
| 9. | YM32TU1047S009 | [2] | FITTING | KOB |
| 10. | YM32TU1047S010 | [1] | LEVER | KOB |
| 11. | YM32TU1047S011 | [2] | BOLT | KOB |
| 12. | YM32TU1047S012 | [4] | NUT | KOB |
| 13. | YM32TU1047S013 | [2] | PIN | KOB |
