神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (84.100.AD[25]) - QUICK COUPLER, HYD. LINE, BOOM (JRB) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
359 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | LC42HU1022P1 | [1] | BRACKET | KOB |
| 2. | LC42HU1023P1 | [1] | BRACKET | KOB |
| 3. | LC42HU1024P2 | [1] | BRACKET | KOB |
| 4. | LC42HU1025P1 | [4] | HYD CONNECTOR | KOB |
| 5. | LC42HU1026P1 | [4] | NUT | KOB |
| 6. | ZM73C10020 | [2] | BOLT,M10x20mm - Course Thread | KOB |
| 7. | PY01P01043D4 | [24] | CABLE TIE,4.80mm W x 251mm L | KOB |
| 8. | ZX25M04575 | [2] | HOSE | KOB |
| 9. | ZS18C12035 | [2] | SCREW,Hex, M12 x 35mm | KOB |
