神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (88.100.06[01]) - HYD. LINE, BOOM, STD (ROTATION) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
680 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YM42HU1019P1 | [1] | TUBE | KOB |
| 2. | YM42H01157P1 | [1] | TUBE | KOB |
| 3. | YM42HU1020P1 | [1] | TUBE | KOB |
| 4. | ZX28N12090 | [2] | HOSE | KOB |
| 5. | YN42H01058P1 | [10] | CLAMP | KOB |
| 6. | YN42H01059P1 | [10] | CLAMP | KOB |
| 7. | ZA23B22000 | [2] | HYD CONNECTOR | KOB |
| 8. | ZS18C12040 | [12] | SCREW,Hex, M12 x 40mm | KOB |
| 9. | ZW26X12000 | [12] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 10. | 2444T2158 | [2] | HYD CONNECTOR | KOB |
| 11. | 2414Z199D050 | [2] | PROTECTIVE SLEEVE | KOB |
| 12. | YM42HU1023P1 | [1] | CLAMP | KOB |
| 13. | YM42HU1024P1 | [1] | CLAMP | KOB |
| 14. | YM42HU1021P1 | [1] | TUBE | KOB |
