神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (88.100.12[03]) - HYD. LINE, CYLINDER (LOAD HOLDING VALVE) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
197 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | HG33H12012G1 | [1] | HYD CONNECTOR | KOB |
| 2. | HH25X06006GA | [1] | HYD CONNECTOR | KOB |
| 3. | LF42H01009P1 | [1] | BRACKET | KOB |
| 4. | PY01P01043D3 | [24] | CABLE TIE,188mm L | KOB |
| 5. | YB28V00003F2 | [1] | HYDRAULIC VALVE | KOB |
| 6. | YM42H01036P1 | [1] | HYD TUBE,1386, 207 mm L | KOB |
| 7. | YN42H01934D3 | [1] | HOSE | KOB |
| 8. | YN43H01097P1 | [1] | CLAMP | KOB |
| 9. | ZD12P01800 | [2] | O-RING | KOB |
| 10. | ZD12P02600 | [1] | O-RING | KOB |
| 11. | ZE13X12000 | [2] | CLAMP | KOB |
| 12. | ZE72X08000 | [1] | PLUG | KOB |
| 13. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB |
| 14. | ZH22X06000 | [4] | HYD CONNECTOR | KOB |
| 15. | ZH22Z04000 | [1] | HYD CONNECTOR | KOB |
| 16. | ZH32X06000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOB |
| 17. | ZS18C10020 | [2] | SCREW,Hex, M10 x 20mm | KOB |
| 18. | ZS18C12055 | [1] | SCREW,Hex, M12 x 55mm | KOB |
| 19. | ZS28C10035 | [4] | SCREW,Hex Socket Head, M10 x 35mm | KOB |
| 20. | ZS28C10065 | [4] | SCREW,Hex Socket Head, M10 x 65mm | KOB |
| 21. | ZW26K10000 | [8] | LOCK WASHER | KOB Superseded by part number: 12581679 |
| 22. | ZW26X10000 | [2] | LOCK WASHER | KOB |
| 23. | ZW26X12000 | [1] | LOCK WASHER | KOB |
| 24. | ZX22M06500 | [1] | HOSE | KOB |
| 25. | ZX30U12110 | [1] | HOSE | KOB |
| 26. | 2420R537D490 | [1] | HOSE,9.6mm ID x 4900mm L | KOB |
