现代零件查询50/60/70D-7A BRAKE SUB HYDRAULIC PIPINGEPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
532 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| N . |
35FQ-50101
|
[1] |
BRAKE PIPING SUB
|
|
| 1. |
81FQ-40700
|
[1] |
BRAKE VALVE ASSY
|
|
| 2. |
81FQ-47120
|
[1] |
SWITCH-PRESSURE
|
|
| 3. |
P913-064027
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 4. |
P910-061033
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 5. |
P930-064019
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 6. |
31N1-40130
|
[1] |
ELBOW-90,LONG,ORFS
|
|
| 7. |
X500-110002
|
[1] |
CONNECTOR-ORFS
|
|
| 8. |
31FT-50240
|
[1] |
FITTING
|
|
| 9. |
X520-110002
|
[1] |
ELBOW-90,ORFS
|
|
| 10. |
S035-083026
|
[4] |
BOLT-W/WASHER
|
|
| 11. |
S631-014004
|
[3] |
O-RING
|
|
| 12. |
S621-012001
|
[3] |
O-RING
|
|
| 13. |
S631-011004
|
[1] |
O-RING
|
|
| 14. |
S611-011001
|
[1] |
O-RING
|
|
