神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (88.100.15[01]) - CONTROL, LINE (PATTERN CHANGER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
442 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN30V00115F1 | [1] | CONTROL VALVE | KOBAssy, |
| 2. | YN64H01349P1 | [1] | BRACKET | KOB |
| 3. | HX33L06090CG | [1] | HYDRAULIC HOSE | KOB |
| 4. | HX33L06100CG | [1] | HYDRAULIC HOSE | KOB |
| 5. | HX33L06100CH | [1] | HYDRAULIC HOSE | KOB |
| 6. | HX33L06090CB | [1] | HYDRAULIC HOSE | KOB |
| 7. | ZH22X06000 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring 237-6006) |
| . . | 237-6006 | [1] | O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro | CAS(Part of ZH22X06000), SAE No. 6-1, Not Shown Superseded by part number: 9617873 |
| 8. | 2444Z2337 | [4] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) |
| . . | ZD12P01100 | [1] | O-RING | KOB(Part of 2444Z2337), ID 10.8mm x OD 13.2mm, Not Shown |
| 9. | 2444Z2516 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) |
| 10. | 2444Z3822 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) Superseded by part number: YY42H01633P1 |
| 11. | ZH32X06000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOB(Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| 12. | 2444Z2338 | [1] | 90 ELBOW | KOB90? -- (1/4 PFx3/8 PF), (Incls. O-Ring ZD12P01100) |
| 13. | 2444Z3155 | [2] | 90 ELBOW,PF 3/8" Fem x PF 3/8" Male | KOB(Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 Superseded by part number: YT42H01128P1 |
| 14. | ZE72X04000 | [4] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| 15. | ZS18C08016 | [4] | SCREW,Hex, M8 x 16mm | KOB |
| 16. | ZS18C10025 | [2] | SCREW,Hex, M10 x 25mm | KOB |
| 17. | ZW16H10000 | [2] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 18. | ZW16H08000 | [4] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
