神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (88.100.15[05]) - SELECTOR, VALVE, ASSY (PATTERN CHANGER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
170 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 0. | YN30V00115F1 | [1] | CONTROL VALVE | KOBAssembly, Incl 1 - 16 |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONName Plate |
| 2. | YN30V00115S002 | [4] | PLUG | KOB |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONHousing |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONSpool |
| 5. | YN30V00115S005 | [1] | LEVER | KOB |
| 6. | YN30V00115S006 | [1] | WASHER | KOB |
| 8. | YN30V00115S008 | [2] | SCREW | KOB |
| 9. | YN30V00115S009 | [1] | BOLT | KOB |
| 10. | YN30V00080S023 | [2] | SCREW | KOB#2x4.8mm |
| 11. | YN30V00115S011 | [3] | PIN | KOB |
| 12. | YN30V00115S012 | [1] | RING | KOB |
| 13. | YN30V00115S013 | [1] | SEAL | KOB |
| 14. | ZD11P02600 | [1] | O-RING | KOB |
| 15. | YN30V00115S015 | [1] | O-RING | KOB |
| 16. | YN30V00115S016 | [4] | O-RING | KOB |
