久保田零件查询T02700 FRONT DRIVE SHAFT AND 6 TH SHAFT TRANSMISSIONEPC Kubota online
广数供应链运营团队, 15 02月, 2025，浏览：
812 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 001. |
6781015610
|
[1] |
SHAFT FRONT DRIVE
|
2.6400(lbs); 1.200
|
| 002. |
1547126740
|
[1] |
BEARING BALL
|
0.1760(lbs); 0.080
|
| 003. |
0461100470
|
[1] |
CIR-CLIP INTERNAL
|
0.0132(lbs); 0.006
|
| 004. |
6781015620
|
[1] |
SEAL OIL
|
0.0352(lbs); 0.016
|
| 005. |
6781015630
|
[1] |
GEAR SPUR 24
|
0.8800(lbs); 0.400
|
| 006. |
0810106304
|
[1] |
BEARING BALL
|
0.3212(lbs); 0.146
|
| 007. |
0461100520
|
[1] |
CIR-CLIP INTERNAL
|
0.0198(lbs); 0.009
|
| 008. |
6711115710
|
[1] |
SHAFT 6
|
2.6400(lbs); 1.200
|
| 009. |
0810106205
|
[1] |
BEARING BALL
|
0.2640(lbs); 0.120
|
| 010. |
6711114450
|
[1] |
COLLAR
|
0.0220(lbs); 0.010
|
| 011. |
6780014450
|
[1] |
COLLAR
|
0.0000(lbs); 0.000
|
| 012. |
6711115720
|
[1] |
GEAR SPUR 27
|
1.1770(lbs); 0.535
|
| 013. |
0882283221
|
[1] |
BEARING NEEDLE
|
0.0440(lbs); 0.020
|
| 014. |
6711114430
|
[1] |
COLLAR
|
0.0132(lbs); 0.006
|
| 015. |
6711114370
|
[1] |
COLLAR
|
0.0154(lbs); 0.007
|
| 016. |
6711115760
|
[1] |
GEAR SPUR 24
|
1.0120(lbs); 0.460
|
| 017. |
0815106305
|
[1] |
BEARING BALL
|
0.5126(lbs); 0.233
|
| 018. |
6711115840
|
[1] |
GEAR SPUR 19
|
0.7150(lbs); 0.325
|
| 019. |
0461200250
|
[1] |
CIR-CLIP EXTERNAL
|
0.0044(lbs); 0.002
|
