现代零件查询50/60/70D-7A CABIN ELECTRIC (OPT)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
548 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
21FQ-36151
|
[1] |
HARNESS-CABIN
|
|
| 1. |
21FQ-46150
|
[1] |
HARNESS CABIN
|
|
| 1. |
21FQ-36151
|
[1] |
HARNESS-CABIN
|
|
| 1. |
21FQ-46150
|
[1] |
HARNESS CABIN
|
|
| 1. |
21FQ-36151
|
[1] |
HARNESS-CABIN
|
|
| 1. |
21FQ-46150
|
[1] |
HARNESS CABIN
|
|
| 2. |
21FV-10510
|
[3] |
LAMP-WORK
|
|
| 3. |
21FF-10120
|
[2] |
LAMP-FLASHER
|
|
| 3-1. |
265134251
|
[1] |
BULB
|
|
| 4. |
21FV-20410
|
[2] |
LAMP-COMBINATION
|
|
| 4. |
21FV-42800
|
[2] |
COMBI LAMP(LED)-REAR
|
|
| 4. |
21FV-20410
|
[2] |
LAMP-COMBINATION
|
|
| 4. |
21FV-20410
|
[2] |
LAMP-COMBINATION
|
|
| 4. |
21FV-42800
|
[2] |
COMBI LAMP(LED)-REAR
|
|
| 4. |
21FV-20410
|
[2] |
LAMP-COMBINATION
|
|
| 4. |
21FV-42800
|
[2] |
COMBI LAMP(LED)-REAR
|
|
| 4-1. |
S863-172510
|
[1] |
BULB(25/10W)
|
|
| 4-2. |
S861-121000
|
[1] |
BULB(10W)
|
|
| 4-3. |
S861-172500
|
[1] |
BULB(25W)
|
|
| 5. |
21LB-20401
|
[2] |
SPEAKER ASSY
|
|
| 6. |
21EH-0011
|
[2] |
LAMP ASSY-ROOM
|
|
| 6-1. |
21E1-49690
|
[1] |
BULB-ROOM LAMP
|
|
| 7. |
21N6-10410
|
[1] |
ANTENA
|
|
| 8. |
21FQ-38010
|
[1] |
WIPER MOTOR ASSY
|
|
| 8. |
21FQ-38011
|
[1] |
WIPER MOTOR ASSY
|
|
| 8. |
21FQ-38010
|
[1] |
WIPER MOTOR ASSY
|
|
| 8. |
21FQ-38011
|
[1] |
WIPER MOTOR ASSY
|
|
| 8. |
21FQ-38010
|
[1] |
WIPER MOTOR ASSY
|
|
| 8. |
21FQ-38011
|
[1] |
WIPER MOTOR ASSY
|
|
| 8. |
21FQ-38010
|
[1] |
WIPER MOTOR ASSY
|
|
| 9. |
24L3-41210
|
[1] |
WIPER ARM-FRONT
|
|
| 10. |
24L3-41300
|
[1] |
WIPER BLADE-FRONT
|
|
| 11. |
24L3-41500
|
[1] |
VALVE-WIPER
|
|
| 12. |
21FQ-30630
|
[1] |
WASHER TANK ASSY
|
|
| 12-1. |
21EG-10140
|
[1] |
TANK
|
|
| 12-2. |
24L3-30660
|
[1] |
CAP
|
|
| 12-3. |
24L3-30710
|
[1] |
PLATE
|
|
| 12-4. |
24L3-30670
|
[1] |
RUBBER-BUSHING
|
|
| 12-5. |
21EG-10130
|
[1] |
PUMP-MOTOR
|
|
| 13. |
21FT-10470
|
[1] |
PLATE
|
|
| 14. |
S131-051026
|
[4] |
SCREW-W/WASHER
|
|
| 14. |
S131-051026
|
[4] |
SCREW-W/WASHER
|
|
| 14. |
S131-051026
|
[4] |
SCREW-W/WASHER
|
|
| 15. |
S161-050106
|
[8] |
SCREW-CROSS R/RD
|
|
| 16. |
S411-050006
|
[8] |
WASHER-SPRING
|
|
| 17. |
S131-051546
|
[4] |
SCREW-W/WASHER
|
|
| 18. |
S151-040156
|
[2] |
SCREW-TAPPING
|
|
| 19. |
S035-082026
|
[2] |
BOLT-W/WASHER
|
|
| 20. |
S543-100002
|
[3] |
CLAMP-TUBE
|
|
| 21. |
S035-061526
|
[2] |
BOLT-W/WASHER
|
|
| 22. |
21EM-30581
|
[1] |
HOSE-RUBBER
|
|
| 23. |
21FT-15312
|
[1] |
CLUSTER
|
|
| 23. |
21FT-15312
|
[1] |
CLUSTER
|
|
| 24. |
S161-040156
|
[4] |
SCREW-CROSS R/ROUND
|
|
| 24. |
S161-040156
|
[4] |
SCREW-CROSS R/ROUND
|
|
| 25. |
21EA-50510
|
[1] |
CHECK VALVE ASSY
|
|
| 27. |
21LM-02200
|
[1] |
HEAD LAMP-LH
|
|
| 27. |
21LM-02200
|
[1] |
HEAD LAMP-LH
|
|
| 27. |
21LM-02200
|
[1] |
HEAD LAMP-LH
|
|
| 28. |
21LM-02210
|
[1] |
HEAD LAMP-RH
|
|
| 28. |
21LM-02210
|
[1] |
HEAD LAMP-RH
|
|
| 28. |
21LM-02210
|
[1] |
HEAD LAMP-RH
|
|
