卡特零件查询（735） 261-0326: WARNING GP-OPERATOR
广数供应链运营团队, 15 02月, 2025，浏览：
199 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| | 3E-7504 | [1] | SWITCH GP-TEMPERATURE(TRANSMISSION OIL) | |
| | 8T-8729 | [2] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 102-8802 | [1] | KIT-RECEPTACLE(2-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | | | |
| | 2U-8863 | [1] | ALARM AS(OIL TEMPERATURE) | |
| | 2U-4500 | [1] | GROMMET | |
| | 7N-7779 | [1] | SOCKET-CONNECTOR(14-GA TO 18-GA) | |
| | 7N-7780 | [1] | PIN-CONNECTOR(14-GA TO 18-GA) | |
| | 7N-9737 | [1] | HOUSING-RECEPTACLE(14-GA TO 18-GA) | |
| | 3T-0304 | [1] | BASE AS-INDICATOR LIGHT | |
| | 6V-8374 | [2] | SCREW-MACHINE(6-32X0.25-IN) | |
| | 261-0847 | [1] | HARNESS AS-CAB | |
| | 2L-8079 | [1] | TERMINAL-RING(14-GA TO 16-GA, 3/8-IN SCREW) | |
| | 2U-4483D | | CABLE(4-M) | |
| | 2U-4489D | | SLEEVE(4-M) | |
| | 2U-4642D | | CABLE(4-M) | |
| | 102-8802 | [1] | KIT-RECEPTACLE(2-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 8T-8730 | [3] | SOCKET-CONNECTOR(16-GA TO 18-GA) | |
| | 261-0846 | [1] | HARNESS AS-DASH(PANEL) | |
| | 2U-4487D | | SLEEVING(1-M) | |
| | 2U-4489D | | SLEEVE(1-M) | |
| | 2U-4642D | | CABLE(2-M) | |
| | 2U-4649 | [1] | TERMINAL | |
| | 7N-7779 | [1] | SOCKET-CONNECTOR(14-GA TO 18-GA) | |
| | 7N-7780 | [1] | PIN-CONNECTOR(14-GA TO 18-GA) | |
| | 7N-9738 | [1] | HOUSING-RECEPTACLE(14-GA TO 18-GA) | |
| | 7U-0922 | [2] | TERMINAL | |
| | 8T-8730 | [1] | SOCKET-CONNECTOR(16-GA TO 18-GA) | |
| | 261-0848 | [1] | HARNESS AS-TRANSMISSION | |
| | 2U-4483D | | CABLE(3-M) | |
| | 2U-4487D | | SLEEVING(3-M) | |
| | 2U-4642D | | CABLE(3-M) | |
| | 8T-8729 | [4] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 155-2270 | [2] | KIT-CONNECTING PLUG(2-PIN) | |
| | | | (EACH INCLUDES PLUG AS, WEDGE & INTERFACE SEAL) |
| | | | |
| | 8T-4137M | [2] | BOLT(M10X1.5X20-MM) | |
| | 4P-7581 | [2] | CLIP(LADDER) | |
| | 261-0301 | [1] | FILM-IDENTIFICATION(TRANSMISSION OIL TEMPERATURE) | |
| | 261-2191 | [1] | FLANGE | |
| | 7N-1996 | [1] | LAMP(24-VOLT)(FAULT INDICATOR) | |
| | 7N-1995 | [1] | LENS(RED) | |
| | 5C-2874M | [2] | NUT(M5X0.8-THD) | |
| | 7Y-7389M | [2] | SCREW(M5X0.8X16-MM) | |
| | 3K-0360 | [1] | SEAL-O-RING | |
| | 4J-0524 | [1] | SEAL-O-RING | |
| | 1P-3707 | [1] | SEAL-RECTANGULAR | |
| | 3S-2093 | [30] | STRAP-CABLE | |
| | 8T-0328 | [2] | WASHER-HARD(5.5X10X1-MM THK) | |
| | 8T-4121 | [2] | WASHER-HARD(11X21X2.5-MM THK) | |
| | D | | ORDER BY THE METER |
| | M | | METRIC PART |
