神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (90.124.AE[02]) - SEAT, AIR SUSPENSION, HARNESS Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
746 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN50S00040D7 | [1] | SWITCH | KOB(Used for Seat Heat) |
| 2. | YN14E01129P1 | [1] | WIRE HARNESS | KOB |
| 3. | YN14E01130P1 | [1] | LABEL | KOB |
| 4. | YN14E01131P1 | [1] | LABEL | KOB |
| 5. | YN14E01132P1 | [1] | LABEL | KOB |
| 6. | YN24S00010P1 | [1] | RELAY | KOB(Used for Horn, Glow, Work Light, Travel Alarm, Cab Work Light, Revolution LH/RH, Auto Idle Stop 1&2, Engine Emerg, Stop, Lever Lock, Alternator, Neutral Stop, Extra, Angle Left/Right, Float, Window washer Motor, Prevent Spark, Wiper Motor Reversing, Restart Prevention, Main, Nibbler Open/Close, Extra Dis-Press, Air Conditioner Blower, Seat Heat) |
