现代零件查询50/60/70D-7A OIL PIPE (TURBOCHARGER)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
452 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 010. |
XJBT-02830
|
[1] |
PIPE COMP-OIL
|
|
| 020. |
XJBR-00336
|
[1] |
BOLT-EYE JOINT
|
|
| 030. |
XJBT-02831
|
[1] |
GASKET
|
|
| 040. |
XJBT-02832
|
[1] |
PIPE COMP-OIL
|
|
| 050. |
XJBT-02833
|
[1] |
GASKET-OIL PIPE
|
|
| 060. |
XJBR-01355
|
[2] |
BOLT-FLANGE
|
|
| 070. |
XJBT-02834
|
[1] |
PIN-BAND
|
|
| 080. |
XJBT-02835
|
[1] |
CLAMP-PIPE
|
|
| 090. |
XJBT-02658
|
[1] |
BOLT-CONNECT
|
|
| 100. |
XJBT-02659
|
[1] |
GASKET
|
|
| 110. |
XJBT-02836
|
[1] |
TUBE-OIL
|
|
| 120. |
XJBT-00866
|
[2] |
CLAMP-HOSE
|
|
