神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (04-15[01]) - HYD LINES, BOOM (SAFETY) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
923 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YB42H01296P1 | [1] | TUBE | KOBRH Boom Cylinder Superseded by part number: 87383004 |
| 2. | ZX20H10072 | [4] | HOSE | KOB |
| 3. | ZD12P02600 | [1] | O-RING | KOB |
| 4. | ZS28C10035 | [4] | SCREW,Hex Socket Head, M10 x 35mm | KOB |
| 5. | YB01V01012P1 | [2] | BAND | KOB |
| 6. | ZS18C10060 | [2] | SCREW,Hex, M10 x 60mm | KOB |
| 7. | ZW26X10000 | [6] | LOCK WASHER | KOB |
| 8. | YB01V01005P1 | [2] | BAND | KOB |
| 9. | YB01V01004P1 | [2] | BAND | KOB |
| 10. | ZS18C10035 | [4] | SCREW,Hex, M10 x 35mm | KOB |
| 12. | ZD12A01600 | [1] | O-RING | KOB |
| 13. | YB42H01295P1 | [1] | TUBE | KOBLH Boom Cylinder Superseded by part number: 87382988 |
