现代零件查询50/60/70D-7K INT F/POSITIONER-LOW (TF-MAST,6/7TON)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
436 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
68FQ-36010
|
[1] |
CARRIAGE-CONTAINER
|
|
| . |
68FQ-36020
|
[1] |
CARRIAGE-CONTAINER
|
|
| . |
6HFQ-36010
|
[1] |
INT F/POSITIONER-LOW
|
|
| . |
6HFQ-36020
|
[1] |
INT F/POSITIONER-LOW
|
|
| 1. |
68FQ-31010
|
[1] |
FORK POSITIONER ASSY
|
|
| 1. |
68FQ-31020
|
[1] |
FORK POSITIONER ASSY
|
|
| 1. |
6HFQ-36110
|
[1] |
INT F/POSITIONER & CARR
|
|
| 1. |
6HFQ-36120
|
[1] |
INT F/POSITIONER & CARR
|
|
| 2. |
61FF-18600
|
[6] |
LOAD R/BRG ASSY(164.5)
|
|
| 2. |
61FF-18610
|
[6] |
LOAD R/BRG ASSY(164.0)
|
|
| 2. |
61FF-18620
|
[6] |
LOAD R/BRG ASSY(165.0)
|
|
| 2. |
61FQ-25100
|
[6] |
COVER
|
|
| 3. |
S601-075004
|
[6] |
RING-RETAINING
|
|
| 4. |
63FF-18301
|
[4] |
SIDE ROLLER ASSY
|
|
| 5. |
61FF-18810-DAC
|
[8] |
ADJUSTABLE SCREW
|
|
| 6. |
S205-201006
|
[12] |
NUT-HEX
|
|
| 7. |
61FF-18011
|
[2] |
HANGER BAR-FORK
|
|
| 7. |
61FQ-18121
|
[2] |
HANGER BAR-FORK
|
|
| 8. |
61FQ-25100
|
[2] |
COVER
|
|
| 9. |
S037-123526
|
[4] |
BOLT-W/WASHER
|
|
| 10. |
S652-810008
|
[4] |
NIPPLE-GREASE
|
|
| 11. |
63FQ-18100
|
[4] |
PLUG-WEAR
|
|
| 12. |
63FF-18220
|
[4] |
SCREW-SET
|
|
| 13. |
61FQ-25320
|
[2] |
SPACER
|
|
| 14. |
61FQ-25350
|
[2] |
SHIM
|
|
| 15. |
S651-810008
|
[2] |
NIPPLE-GREASE
|
|
