久保田零件查询T10700 CONTROL VALVE [SECTION PARTS] ## S.No.>=11643 HYDRAULIC SYSTEMEPC Kubota online_久保田Kubota_工程机械

Pos.	Part No	Qty	Parts name	Comments
001.	6783037305	[1]	ASSY VALVE CONTROL	REF.No.002 TO 080 16.5000(lbs); 7.500
003.	6753138220	[1]	COVER VALVE	1.4300(lbs); 0.650
004.	6753138232	[1]	GASKET VALVE COVER	0.0000(lbs); 0.000
005.	6753138242	[1]	COVER RELIEF	0.8360(lbs); 0.380
006.	6753138252	[1]	GASKET RELIEF COVER	0.0000(lbs); 0.000
009.	6753138280	[1]	TUMBLER SPOOL 1	0.0352(lbs); 0.016
010.	6753138290	[1]	PLATE CONNECTING	0.0660(lbs); 0.030
011.	3715036420	[1]	TUMBLER SPOOL 2	0.0440(lbs); 0.020
012.	0461300050	[1]	CIR-CILP EXTERNAL	0.0022(lbs); 0.001
013.	0211250080	[1]	NUT	0.0066(lbs); 0.003
014.	6753138310	[1]	U NUT	0.0088(lbs); 0.004
015.	6753138320	[1]	POPPET 2	0.0220(lbs); 0.010
016.	6753138330	[1]	SPRING 2	0.0022(lbs); 0.001
017.	6753138340	[1]	PLUG 2	0.0704(lbs); 0.032
018.	0541100332	[1]	PIN SPRING	0.0022(lbs); 0.001
019.	0481100070	[1]	O RING	0.0022(lbs); 0.001
020.	6753138350	[1]	ROD PUSH	0.0220(lbs); 0.010
021.	0201250060	[2]	NUT	0.0044(lbs); 0.002
022.	6753138360	[1]	PLATE	0.0330(lbs); 0.015
023.	0105050610	[1]	BOLT	0.0000(lbs); 0.000
024.	0451250060	[1]	WASHER SPRING	0.0022(lbs); 0.001
026.	6753138380	[1]	COLLAR	0.0220(lbs); 0.010
027.	6783038610	[1]	SPRING RETURN	0.0264(lbs); 0.012
028.	6711137290	[1]	WASHER SPECIAL	0.0066(lbs); 0.003
029.	0401350100	[1]	WASHER PLAIN	0.0088(lbs); 0.004
030.	0401350060	[1]	WASHER PLAIN	0.0022(lbs); 0.001
031.	0451250060	[1]	WASHER SPRING	0.0022(lbs); 0.001
032.	0105350614	[1]	BOLT	0.0110(lbs); 0.005
033.	0541100518	[1]	PIN SPRING	0.0044(lbs); 0.002
034.	6753138410	[1]	SHAFT GUIDE ARM	0.1540(lbs); 0.070
035.	6753138420	[1]	ARM VALVE GUIDE	0.0660(lbs); 0.030
036.	6711137570	[1]	BOLT	0.0198(lbs); 0.009
037.	0481110100	[1]	O RING	0.0022(lbs); 0.001
038.	6753138430	[1]	POPPET 1	0.0330(lbs); 0.015
039.	6753138440	[1]	SPRING 1	0.0022(lbs); 0.001
040.	6753138450	[1]	PLUG 1	0.1100(lbs); 0.050
041.	0481100090	[1]	O RING	0.0022(lbs); 0.001
042.	6753138460	[1]	POPPET	0.0440(lbs); 0.020
043.	6753138470	[1]	SPRING	0.0022(lbs); 0.001
044.	6753138480	[1]	PLUG	0.1628(lbs); 0.074
045.	6753138490	[1]	PLATE	0.2992(lbs); 0.136
046.	0471400100	[1]	GASKET	0.0044(lbs); 0.002
047.	0211650100	[1]	NUT	0.0088(lbs); 0.004
048.	6711137320	[1]	SEAT VALVE	0.0220(lbs); 0.010
049.	0481100120	[1]	O RING	0.0022(lbs); 0.001
050.	6711137330	[1]	POPPET	0.0176(lbs); 0.008
051.	6753138510	[1]	SCREW	0.0396(lbs); 0.018
052.	6711137360	[1]	SPRING RELIEF 1	0.0220(lbs); 0.010
053.	6753138520	[1]	SUPPORT SPRING	0.0220(lbs); 0.010
054.	6753138530	[1]	PLUG RELIEF	0.1760(lbs); 0.080
055.	0481110180	[2]	O RING	0.0022(lbs); 0.001
056.	6753138540	[2]	RING BUCK UP	0.0022(lbs); 0.001
057.	6753138550	[1]	PISTON	0.0132(lbs); 0.006
058.	0347001212	[1]	SCREW STOP	0.0176(lbs); 0.008
059.	6753138560	[1]	ARM CONTROL	0.1760(lbs); 0.080
060.	0481100140	[1]	O RING	0.0022(lbs); 0.001
061.	6753138570	[1]	PLATE STOP 2	0.0440(lbs); 0.020
062.	0105050610	[1]	BOLT	0.0000(lbs); 0.000
063.	0451250060	[1]	WASHER SPRING	0.0022(lbs); 0.001
064.	6753138580	[1]	SHAFT FEEDBACK LEVER	0.1540(lbs); 0.070
065.	6753138590	[1]	LEVER SPOOL	0.0880(lbs); 0.040
066.	0481100140	[1]	O RING	0.0022(lbs); 0.001
067.	6753138612	[1]	PLATE 1	0.0264(lbs); 0.012
068.	0105050610	[1]	BOLT	0.0000(lbs); 0.000
069.	0451250060	[1]	WASHER SPRING	0.0022(lbs); 0.001
070.	6753138620	[1]	ARM FEEDBACK	0.1320(lbs); 0.060
071.	0541100518	[1]	PIN SPRING	0.0044(lbs); 0.002
072.	0105350680	[6]	BOLT	0.0440(lbs); 0.020
073.	0105350665	[6]	BOLT	0.0330(lbs); 0.015
074.	0451250060	[12]	WASHER SPRING	0.0022(lbs); 0.001
075.	0401350100	[2]	WASHER PLAIN	0.0088(lbs); 0.004
076.	6753138630	[2]	WASHER SPRING	0.0044(lbs); 0.002
077.	6783038642	[1]	LEVER CONTROL	0.6600(lbs); 0.300
078.	0211650100	[2]	NUT	0.0088(lbs); 0.004
079.	6783038650	[1]	COLLAR	0.0880(lbs); 0.040
080.	0541100518	[1]	PIN SPRING	0.0044(lbs); 0.002
081.	6753138710	[1]	METAL FEEDBACK	0.3080(lbs); 0.140
082.	6753138720	[1]	ROD FEEDBACK 1	0.1980(lbs); 0.090
083.	6753138730	[1]	ROD FEEDBACK 2	0.0660(lbs); 0.030
084.	0211250080	[2]	NUT	0.0066(lbs); 0.003
085.	0401250080	[2]	WASHER PLAIN	0.0022(lbs); 0.001
086.	0551150218	[2]	PIN SNAP	0.0022(lbs); 0.001
087.	0112350816	[2]	BOLT	0.0242(lbs); 0.011
088.	0401350060	[14]	WASHER PLAIN	0.0022(lbs); 0.001
