神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (09-01[01]) - ENGINE, SENSOR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
964 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 20. | 11106234 | [4] | BOLT,Hex, M10 x 1.5 x 25 mm, Cl 10.9, Full Thd | BUR Superseded by part number: 11106231 |
| 22. | 14496631 | [4] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | LEC Superseded by part number: 14496621 |
| 23. | 71451711 | [1] | SENSOR,M14 x 1.5 | LECWater Temp. |
| 24. | 71451954 | [1] | PRESSURE SWITCH | LEC(Used for Engine Oil Pressure) Superseded by part number: 504085003 |
| 26. | 71488736 | [2] | SEAL | LEC Superseded by part number: 5169544 |
| 27. | YN02P01032P1 | [1] | HYD CONNECTOR | KOB |
| 29. | 87550707 | [1] | FAN | SM Superseded by part number: YN75S00007P1 |
| 33. | 72109072 | [1] | HYD CONNECTOR | LEC |
| 33A. | 72109073 | [1] | O-RING,1.5mm Thk x 8mm ID, 90 Duro | LEC |
| 40. | 87568522 | [1] | THERMOSTATIC SWITCH,On, 10 Degrees C, 50 Degrees F; Off, -12 Degrees C, 10.4 Degrees F | SM(Used for Engine Temp Sensor) |
| 41. | 71450201 | [1] | HYD CONNECTOR | SM |
