凯斯零件查询(FLX4300) - FLOATER - 1999 (8/99-9/02) (01-004) - STEERING ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
392 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN2396330
|
[1] |
STEERING COLUMN
|
BN
Assy
|
| 2. |
BN2298398
|
[1] |
STEERING WHEEL
|
BN
|
| . . |
BN2396330-001
|
[1] |
REPAIR KIT
|
BN
Turn Signal Repair Kit
|
| 3. |
BN2292560
|
[1] |
YOKE
|
BN
W/ U-Joint
|
| . . |
BN2294188
|
[1] |
REPAIR KIT
|
BN
|
| 4. |
BN305104
|
[2] |
FLANGE NUT
|
BN
3/8-16, FLN, G8 Superseded by part number: 329-286
|
| 5. |
BN312561
|
[1] |
CAP
|
BN
Steering Wheel, Blk
|
| 6. |
BN315609
|
[1] |
Column Steering
|
|
| 7. |
BN305105
|
[1] |
FLANGE BOLT,3/8" - 24, Gr 8
|
BN
3/8-24, FLN, G8
|
| 8. |
BN7142247
|
[1] |
MOUNTING PLATE
|
BN
Steering Valve
|
| 9. |
BN315608
|
[2] |
SUPPORT
|
BN
Column Steering
|
| 10. |
BN7142246
|
[1] |
MOUNTING PARTS
|
BN
Steering Valve
|
| 11. |
BN50254
|
[8] |
BOLT,3/8"-16 x 1", Stainless
|
BN
|
| 12. |
BN305108
|
[4] |
FLANGE BOLT,3/8" - 16, SST
|
BN
3/8-16, FLN, SS
|
| 13. |
BN1913634C
|
[2] |
3/8-16 X 1, HH, G8
|
|
| 14. |
BN305106
|
[4] |
SCREW,3/8" - 24 x 3/4", Gr 8
|
BN
3/8-24 X .75, HH, G8 Superseded by part number: 86514065
|
| 15. |
BN2292371
|
[8] |
NUT
|
BN
3/8, FW, G8
|
| 16. |
BN50146
|
[8] |
WASHER,3/8", Stainless
|
BN
|
| 17. |
BN305101
|
[1] |
SCREW,Hex, 5/16" - 24 x 2", Gr 8
|
BN
5/16-24 X 2, HH, G8
|
| 18. |
BN305100
|
[1] |
FLANGE BOLT,5/16" - 24, Gr 8
|
BN
5/16-24, FLN, G8
|
| 19. |
BN2395066
|
[2] |
SEAL
|
BN
Trim, SD-161
|
| 20. |
BN305102
|
[4] |
SCREW,5/16", Gr 8
|
BN
5/16, LW, G8
|
| 21. |
BN305103
|
[4] |
SCREW,5/16" - 18 x 3/4", Gr 8
|
BN
5/16-18 X .75, HH, G8
|
| 22. |
BN305107
|
[1] |
SCREW,Hex, 3/8" - 24 x 1 3/4", Gr 8
|
BN
3/8-24 X 1.75, HH, G8
|
| 23. |
BN305109
|
[2] |
FLANGE BOLT,7/16" - 20, Gr 8
|
BN
7/16-20, FLN, G8
|
| 24. |
BN50816
|
[2] |
7/16-20 X 1.5, HH, G8
|
|
