神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (05.100.03[01]) - FILTERS Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
863 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87646666 | [1] | ENGINE OIL FILTER | KOBSpin-On Superseded by part number: 84228488 |
| 2. | YM11P01033P1 | [1] | AIR FILTER | KOBPrimary Superseded by part number: 87682990 |
| 2. | YM11P01032P1 | [1] | AIR FILTER | KOBSecondary Superseded by part number: 87683000 |
| 3. | 87435524 | [1] | FUEL FILTER | BHBM10 Drain Port Superseded by part number: 84348882 |
| 4. | YN57V00002S010 | [1] | ELEMENT | KOBBreather Superseded by part number: 47640920 |
| 5. | YN52V01013P1 | [1] | HYDRAULIC OIL FILTER | KOBTank Superseded by part number: YN52V01021P1 |
| 6. | YN50V01015P3 | [1] | CAB FILTER | SMOuter Superseded by part number: YN50V01015P3P |
| 7. | YN50V01014P1 | [1] | CAB FILTER,124mm W x 491.5mm L | SMInner Superseded by part number: YN50V01014P1P |
| 8. | 87646724 | [1] | FUEL FILTER | KOBM14 Drain Port Superseded by part number: 84565884 |
| 9. | 87438159 | [1] | SENSOR | FAR |
