神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (07-21[00]) - NAME PLATE INSTALLATION, (PATTERN CHANGE CAB) LOCATION (YN22T00341F2) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
954 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN20T01863P1 | [1] | LABEL | KOBDecal, Multi Warnings and Notice |
| 2. | PH20T01018P1 | [2] | WARNING DECAL | KOBDecal, Hammer Hand and Man running |
| 3. | YN20T01864P1 | [1] | LABEL | KOBDecal, Lever Control Unlock and Control Lockout |
| 5. | YN20T01407P1 | [1] | LABEL | KOBDecal, Kobelco Construction Machine Co. LTD. |
| 6. | YN20T01862P1 | [1] | LABEL | KOBDecal, Intelligent Total Control System |
| 7. | ZL11M06008 | [1] | LABEL | KOBDecal, Window Lock and Unlock |
| 8. | YN20T01339P1 | [2] | LABEL | KOBDecal, Caution -- Be careful not to pinch your hand(s) when operating the lever. |
| 9. | YN20T01799P1 | [1] | LABEL | KOBDecal, Unlock and Locked |
| 10. | YN20T01800P1 | [1] | LABEL | KOBDecal, Lock and Unlocked |
| 11. | YN20T01639P1 | [1] | LABEL | KOBDecal, Caution, Swing parking brake release switch is installed on the rear side this cover. |
| 12. | YN20T01475P1 | [1] | LABEL | KOBHolder |
| 13. | YN20T01476P1 | [1] | LABEL | KOBDecal, Control location and positions |
| 14. | YN20T01039P1 | [1] | WARNING DECAL | KOBDecal, Warning, This machine equipped with a rotary multi-control valve which allows changing of… |
