神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (02-13[02]) - FUEL LINES, SHUT-OFF VALVE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
484 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | LQ21P01005P1 | [2] | COUPLING,M14 x 1.5 x 12mm ID x 7mm ID | KOB |
| 2. | YY21P01002P1 | [2] | PACKING | KOB Superseded by part number: VIG0293414080 |
| 3. | PY01P01043D3 | [2] | CABLE TIE,188mm L | KOB |
| 4. | YN25V00006P1 | [1] | SHUT-OFF VALVE | KOB |
| 5. | YN21P01062P1 | [2] | HYD CONNECTOR | KOB |
| 6. | YN21P01064P1 | [1] | HOSE | KOBFuel Tank to Stop Valve |
| 7. | YN21P01063P1 | [1] | HOSE,6mm ID x 450mm L | KOBWater Separtor to Stop Valve |
