神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (02-42[00]) - PLATE INSTALLATION, FLOOR (YN03M00162F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
805 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| A1. | YN03M00163P1 | [1] | PLATE | KOBPlate, Floor |
| B. | YN03M00132F1 | [1] | Floor Plate Installation, Incls. Refs. B1 - B8 | |
| B1. | YN03M01573P1 | [2] | SILENTBLOC,110mm OD x 201mm L | KOB |
| B2. | ZM22C10035 | [16] | BOLT | KOBM10x1.50x35mm (Incls. Washer & Lockwasher) |
| B3. | ZW16H16000 | [4] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| B4. | ZN18C16013 | [4] | NUT | KOBM16x2.0mm |
| B5. | YN03M01695P1 | [2] | SILENTBLOC,110mm OD x 171mm L | KOB |
| B6. | YN03M01671P1 | [1] | FOAM INSULATION | KOB |
| B8. | YN03M01963P1 | [1] | RUBBER BAND | KOB |
