神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (02-85[00]) - HARNESS ASSEMBLY, UPPER (FRAME MOUNTING) (YN13E00137F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
613 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN13E01509P1 | [1] | HARNESS | KOB1 Piece Harness (Includes 5 - YN02D01001P1 Diodes) ~8/27/2008 Superseded by part number: YN13E01509P4 |
| 1-1. | YN02D01001P1 | [5] | DIODE,3 Amp, 400V | KOB(Supplied with YN13E01509P1), Not Shown (Black) |
| 1. | YN13E01518P1 | [1] | HARNESS | KOB(Attaches to Upper Harness, Solenoid Valve Solenoids, Proportional Solenoids, Stepping Motor, Engine Stop Solenoid, Battery Relay), Start Year: 27-AUG-08 |
| 1. | YN13E01519P1 | [1] | HARNESS | KOB(Attaches to Controller, Upper Harness, Floor Harness, Fuse/Relay Box), Start Year: 27-AUG-08 |
| 2. | YN13E01462P1 | [1] | CABLE,2670mm L | KOB |
| 7. | LE13E01006P1 | [1] | HARNESS | KOB100mm Long (3-15/16 in) |
| 22. | EZ09H01066P1 | [2] | CLIP | KOBClamp, Double -- Ø32x93mm Long |
| 26. | PY01P01043D3 | [1] | CABLE TIE,188mm L | KOB |
| 29. | ZM73C08020 | [2] | BOLT,M8x20mm - Course Thread | KOB(Incls. Washer) |
| 36. | LC13E01150P1 | [1] | PLATE | KOB |
| 39. | ZM73C10020 | [2] | BOLT,M10x20mm - Course Thread | KOB(Incls. Washer) |
