神钢零件查询(SK170-8) - HYDRAULIC EXCAVATOR - TIER 3 ROPS (NA) ASN YM07U1901 (4/11-12/12) (08-002[00]) - CYLINDER BLOCK (101580210001) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
515 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 6. | 4895392 | [2] | HEX SOCKET PLUG,M18 x 1.5 | TORM18x1.50mm (Incls. O-Ring 4895393) |
| 7. | 4895393 | [1] | O-RING,2.2mm Thk x 15.3mm ID | TOR(Part of 4895392), ID 15.3 x OD 19.7 x Th 2.2mm |
| 8. | 4895049 | [2] | DOWEL,M16.05 x 10 | TOR |
| 9. | J931623 | [8] | TAPPET | CAS Superseded by part number: 4895180 |
| . . | 2852202 | [4] | NOZZLE, PISTON COOLI | TOR Superseded by part number: 5801910166, 5801639154 |
| 10. | 2852203 | [1] | NOZZLE, PISTON COOLI | TOR Superseded by part number: 5801910166, 5801639154 |
| 10A. | 4894218 | [1] | SCREW,Special, M8 x 20 | TORM08x1.25x20mm |
| 11. | REF | [1] | INSTRUCTION | NHPiston -- See Figure 08-019 |
| 12. | REF | [1] | INSTRUCTION | NHCamshaft -- See Figure 08-022 |
