卡特零件查询（735） 153-7076: ENGINE AR-COMPLETE
广数供应链运营团队, 15 02月, 2025，浏览：
355 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| | 187-9076Y | [1] | ALTERNATOR GP-CHARGING | |
| | 190-6562Y | [1] | BELT TENSIONER GP | |
| | 172-1248Y | [1] | COMPRESSOR GP-REFRIGERANT | |
| | 159-9107Y | [1] | CONNECTION GP-ELECTRICAL(CYLINDER HEAD GROUND) | |
| | 173-7072Y | [1] | CONTROL & MTG GP-ENGINE ELEK | |
| | 168-8312Y | [1] | COOLER GP-BRAKE & TORQUE CONV | |
| | 7W-2206Y | [1] | COOLER GP-ENGINE OIL | |
| | 8N-4266Y | [1] | COVER GP-ACCESSORY DRIVE | |
| | 107-6736Y | [1] | COVER GP-CYLINDER BLOCK(TURBOCHARGER DRAIN COVER) | |
| | 107-6737Y | [1] | COVER GP-CYLINDER BLOCK | |
| | 109-7423Y | [1] | COVER GP-CYLINDER BLOCK | |
| | 1W-8341Y | [1] | COVER GP-FLYWHEEL HOUSING | |
| | 150-4278Y | [1] | COVER GP-FRONT HOUSING(ACCESS) | |
| | 6I-4683Y | [1] | COVER GP-VALVE MECHANISM | |
| | 4P-5893Y | [1] | DAMPER GP | |
| | 207-8799Y | [1] | DRIVE GP-ACCESSORY | |
| | 153-7078Y | [1] | ENGINE AR-CORE | |
| | 148-7486Y | [1] | ENGINE BRAKE GP | |
| | 112-2644Y | [1] | FASTENER GP-FRONT HOUSING | |
| | 150-3345Y | [1] | FASTENER GP-FRONT HOUSING | |
| | 227-5372Y | [1] | FILTER & LINES GP-ENGINE OIL | |
| | 173-7043Y | [1] | FLYWHEEL GP | |
| | 183-6195Y | [1] | FUMES DISPOSAL GP | |
| | 188-9134Y | [1] | GEAR GP-REAR | |
| | 183-2996Y | [1] | GUIDE GP-OIL LEVEL GAUGE(ENGINE) | |
| | 144-3527Y | [1] | HOUSING GP-FLYWHEEL | |
| | 124-6822Y | [1] | HOUSING GP-FRONT | |
| | 111-2088Y | [1] | LIFTING GP-ENGINE(REAR) | |
| | 112-2418Y | [1] | LIFTING GP-ENGINE(FRONT) | |
| | 127-9039Y | [1] | LINES GP-AIR | |
| | 187-9077Y | [1] | LINES GP-AIR | |
| | 4N-1128Y | [1] | LINES GP-ENGINE OIL | |
| | 188-9138Y | [1] | LINES GP-FUEL | |
| | 183-2770Y | [1] | LINES GP-TURBOCHARGER OIL | |
| | 143-9161Y | [1] | LINES GP-WATER | |
| | 140-8644Y | [1] | MANIFOLD GP-EXHAUST | |
| | 175-4859Y | [1] | MOUNTING GP-ALTERNATOR | |
| | 4N-0756Y | [1] | PAN GP-OIL | |
| | 145-6851Y | [1] | PLUG GP-CYLINDER BLOCK | |
| | 170-1757Y | [1] | PULLEY GP-CRANKSHAFT | |
| | 150-4279Y | [1] | PUMP & MTG GP-FUEL TRANSFER(REAR) | |
| | 205-0347Y | [1] | PUMP GP-FUEL PRM & SEC FILTER | |
| | 100-9347Y | [1] | PUMP GP-WATER | |
| | 102-7664Y | [1] | SENSOR & MTG GP-PRESSURE | |
| | 188-9395Y | [1] | SENSOR GP-TEMPERATURE | |
| | 9L-6671Y | [1] | SHIELD GP-MANIFOLD | |
| | 137-9427Y | [1] | STARTING MOTOR GP-ELECTRIC | |
| | 185-6278Y | [1] | SUPPORT GP-ENGINE(FRONT) | |
| | 194-4025Y | [1] | WIRING GP-ELECTRONIC CONTROL | |
| | | | |
| | | | FOR A LIST OF RELATED PARTS THAT MAY BE REQUIRED FOR THE ENGINE REBUILD IN ADDITION TO THE KIT CONSIST, PLEASE VISIT: |
| | | | |
| | | | HTTPS://DEALER.CAT.COM/RELATED |
| | | | |
| | | | PLEASE USE THE GASKET KIT LINK IN SIS OR CONTACT YOUR LOCAL DEALER FOR THE LATEST GASKET KIT INFORMATION |
| | | | |
| | | | |
| | | | AVAILABLE REPAIR KIT(S): |
| | 380-0468Y | [1] | KIT-ENGINE OVERHAUL(BRONZE) | |
| | 380-1593Y | [1] | KIT-ENGINE OVERHAUL(SILVER) | |
| | 20R-0684Y | [1] | KIT-ENGINE OVERHAUL(GOLD) | |
| | 20R-1105Y | [1] | KIT-ENGINE OVERHAUL(PLATINUM) | |
| | | | ( THESE GOLD, SILVER, & PLATINUM KITS ARE ADAPTABLE TO ENGINE SERIAL NUMBERS BET00198-UP. |
| | | | FOR EARLIER SERIAL NUMBERS CONTACT YOUR LOCAL CAT DEALER.) |
| | R | | REMANUFACTURED PART MAY BE AVAILABLE |
| | Y | | SEPARATE ILLUSTRATION |
