久保田零件查询T10602 HOOD (BONNET) [FR] HOOD(BONNET)/CHASSISEPC Kubota online
广数供应链运营团队, 15 02月, 2025，浏览：
160 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 010. |
6637454100
|
[1] |
COMP.BONNET
|
15.4000(lbs); 7.000
|
| 020. |
6780054840
|
[1] |
TAPE
|
0.0176(lbs); 0.008
|
| 030. |
6721155520
|
[2] |
TAPE SOFT SIDE
|
0.0220(lbs); 0.010
|
| 030. |
H672055520
|
[2] |
TAPE SOFT SIDE
|
0.0220(lbs); 0.010
|
| 040. |
6780054130
|
[1] |
BLOCK
|
0.0264(lbs); 0.012
|
| 050. |
6636154140
|
[2] |
BLOCK
|
0.0220(lbs); 0.010
|
| 060. |
6636154180
|
[1] |
BLOCK
|
0.0880(lbs); 0.040
|
| 070. |
6630154290
|
[1] |
TRIM
|
0.2860(lbs); 0.130
|
| 080. |
6751154262
|
[1] |
HOLDER RH
|
0.6732(lbs); 0.306
|
| 090. |
6780054272
|
[1] |
HOLDER LH
|
0.7040(lbs); 0.320
|
| 100. |
0112351020
|
[4] |
BOLT
|
0.0440(lbs); 0.020
|
| 110. |
0401350100
|
[4] |
WASHER PLAIN
|
0.0088(lbs); 0.004
|
| 120. |
0512250855
|
[2] |
PIN JOINT
|
0.0484(lbs); 0.022
|
| 130. |
0401350080
|
[2] |
WASHER PLAIN
|
0.0066(lbs); 0.003
|
| 140. |
0551150215
|
[2] |
PIN SPLIT
|
0.0022(lbs); 0.001
|
