卡特零件查询（735） 227-0748: HYDRAULIC AR-MACHINE
广数供应链运营团队, 15 02月, 2025，浏览：
901 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| | 238-8543Y | [1] | BATTERY & WIRING GP | |
| | 197-7201Y | [1] | BREATHER GP-POWER TRAIN | |
| | Y | [1] | CAB AR |
| | 152-7099Y | [1] | FENDER & SUPPORT GP | |
| | | | S/N B1N1-627 |
| | 289-4714Y | [1] | FENDER & SUPPORT GP | |
| | | | S/N B1N628-879 |
| | 152-6946Y | [1] | LINES GP-AIR CONDITIONER(HYDRAULIC OIL) | |
| | 166-3950Y | [1] | LINES GP-BRAKE COOLING | |
| | 199-6426Y | [1] | LINES GP-DIFFERENTIAL LOCK | |
| | 229-8240Y | [1] | LINES GP-DRAIN(ENGINE OIL) | |
| | 242-1768Y | [1] | LINES GP-FUEL | |
| | 234-5551Y | [1] | LINES GP-HEATER | |
| | 152-7101Y | [1] | LINES GP-HOIST | |
| | 227-5290Y | [1] | LINES GP-PILOT | |
| | 251-3503Y | [1] | LINES GP-PRESSURE TEST | |
| | 152-7100Y | [1] | LINES GP-PUMP(BRAKE CONTROL) | |
| | 153-1137Y | [1] | LINES GP-PUMP(HYDRAULIC FAN) | |
| | 166-5846Y | [1] | LINES GP-PUMP(HOIST) | |
| | 227-5289Y | [1] | LINES GP-PUMP(STEERING) | |
| | 266-7083Y | [1] | LINES GP-PUMP(RADIATOR FAN) | |
| | 166-3944Y | [1] | LINES GP-PUMP(SECONDARY STEERING) | |
| | 166-3938Y | [1] | LINES GP-RETURN(HOIST PILOT) | |
| | 152-7103Y | [1] | LINES GP-STEERING(CYLINDER) | |
| | 139-4593Y | [1] | MOUNTING GP-ROPS | |
| | 229-8091Y | [1] | MUFFLER GP | |
| | 152-6962Y | [1] | PUMP & MTG GP-SECONDARY STEER | |
| | 234-5613Y | [1] | SHIELD GP-EXHAUST | |
| | 152-7115Y | [1] | STEP GP | |
| | 203-4720Y | [1] | SUPPORT GP-HITCH LINES | |
| | 141-6878Y | [1] | TANK & MTG GP-FUEL | |
| | 141-6884Y | [1] | TANK & MTG GP-HYDRAULIC(HOIST) | |
| | 189-0601Y | [1] | TANK & MTG GP-HYDRAULIC(STEERING) | |
| | 152-7117Y | [1] | TILT GP-PLATFORM | |
| | 266-6433Y | [1] | VALVE & MTG GP-HYDRAULIC FAN | |
| | 152-7116Y | [1] | WALKWAY GP | |
| | | | S/N B1N1-627 |
| | 289-4716Y | [1] | WALKWAY GP | |
| | | | S/N B1N628-879 |
| | Y | | SEPARATE ILLUSTRATION |
