约翰迪尔零件查询762C ATT - ATTACHMENTS ENGINE HARVESTER HEAD 762C F048250 11 2.1 TF1419 [TF1419]EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
520 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
F046971
|
[1] |
HARVESTER HEAD
|
|
| 1. |
F046878
|
[1] |
LEG ASSY
|
|
| 2. |
F048101
|
[1] |
Knife
|
|
| |
F604448
|
[2] |
Knife
|
|
| |
F604449
|
[2] |
Knife
|
|
| |
F017840
|
[1] |
Knife
|
|
| |
F049291
|
[1] |
Knife
|
|
| |
F604448
|
[2] |
Knife
|
|
| |
F604449
|
[2] |
Knife
|
|
| |
F050480
|
[1] |
Knife
|
|
| 3. |
F034274
|
[1] |
WHEEL MOUNTING
|
|
| |
F034273
|
[1] |
WHEEL MOUNTING
|
|
| 4. |
F048116
|
[1] |
Tightener
|
|
| |
F048177
|
[1] |
Tightener
|
|
| 5. |
F048331
|
[1] |
HYDRAULIC VALVE
|
|
| 6. |
F043395
|
[1] |
HHM BOX
|
|
| 7. |
F602362
|
[1] |
Link
|
|
| |
F602359
|
[1] |
Link
|
|
| 8. |
F022484
|
[2] |
FEED WHEEL
|
|
| |
F049324
|
[2] |
FEED WHEEL
|
|
| |
F011178
|
[2] |
FEED WHEEL
|
|
| |
F034742
|
[2] |
FEED WHEEL
|
|
| |
F049324
|
[2] |
FEED WHEEL
|
|
| 9. |
F049249
|
[1] |
Measuring Wheel
|
|
| 10. |
F030111
|
[2] |
Washer
|
|
| |
F029919
|
[2] |
Washer
|
|
| 11. |
F003554
|
[4] |
Screw
|
|
| 12. |
F039611
|
[4] |
Washer
|
|
| 13. |
F015049
|
[4] |
SPHERICAL BEARING
|
|
| 14. |
F030978
|
[2] |
Snap Ring
|
|
| 15. |
F046322
|
[8] |
Bearing
|
|
| 16. |
F003531
|
[10] |
Screw
|
|
| 17. |
F005551
|
[18] |
Lock Washer
|
|
| 18. |
F046013
|
[8] |
Pin
|
|
| 19. |
F011445
|
[4] |
Hydraulic Cylinder
|
|
| 20. |
F011186
|
[20] |
Sleeve
|
|
| 21. |
F046014
|
[2] |
Pin
|
|
| 22. |
F011198
|
[2] |
Lock Nut
|
|
| 23. |
F007292
|
[2] |
Washer
|
|
| 24. |
F007290
|
[2] |
Sleeve
|
|
| 25. |
F017736
|
[1] |
Hydraulic Cylinder
|
|
| 26. |
F007291
|
[2] |
Shaft
|
|
| 27. |
F003170
|
[10] |
Washer
|
|
| 28. |
F003501
|
[2] |
Screw
|
|
| 29. |
F012697
|
[4] |
Washer
|
|
| 30. |
F018838
|
[4] |
Lock Nut
|
|
| 32. |
F005494
|
[4] |
Lock Nut
|
|
| 33. |
F003554
|
[4] |
Screw
|
|
| 34. |
F003536
|
[8] |
Screw
|
|
| 35. |
F600299
|
[1] |
Bracket
|
|
| 36. |
F612852
|
[1] |
Cover
|
|
| 37. |
F005012
|
[4] |
Lock Washer
|
|
| 38. |
F031177
|
[4] |
Spacer
|
|
| 39. |
F045157
|
[2] |
Pin
|
|
| 39. |
F601847
|
[2] |
Pin
|
|
| 40. |
F013393
|
[%] |
Shim
|
|
| 41. |
F029982
|
[2] |
Hydraulic Cylinder
|
|
| 42. |
F031184
|
[2] |
Lock Nut
|
|
| 43. |
F600624
|
[1] |
Case
|
|
| 44. |
F013894
|
[2] |
SPHERICAL BEARING
|
|
| 45. |
F005626
|
[20] |
Lubrication Fitting
|
|
| 46. |
F600871
|
[1] |
Bracket
|
|
| 47. |
F049138
|
[2] |
Washer
|
|
| 48. |
F003432
|
[2] |
Cap Screw
|
|
| 49. |
F015955
|
[2] |
Snap Ring
|
|
| 50. |
F048147
|
[1] |
FASTENING PLATE
|
|
| 51. |
F611519
|
[1] |
Plate
|
|
| 52. |
F039571
|
[2] |
Cap
|
|
| 53. |
-------
|
[1] |
MACHINE PLATE
|
|
| 54. |
F021485
|
[2] |
Screw
|
|
| 55. |
F017389
|
[2] |
Pin
|
|
| 56. |
F017387
|
[2] |
Pin
|
|
| 57. |
F039573
|
[2] |
Shim
|
|
| 58. |
F039574
|
[2] |
Shim
|
|
| 59. |
F005596
|
[13] |
Screw
|
|
| 60. |
F041181
|
[1] |
PROTECTION PLATE
|
|
| 61. |
F041182
|
[2] |
PROTECTION PLATE
|
|
| 62. |
-------
|
[2] |
Decal Kit
|
|
| 63. |
F045892
|
[1] |
Bracket
|
|
| 64. |
F003541
|
[4] |
Screw
|
|
| 65. |
F049053
|
[12] |
PIN SCREW
|
|
| 66. |
F049054
|
[12] |
Nut
|
|
| 67. |
F002805
|
[2] |
Lock Washer
|
|
| 68. |
F601530
|
[1] |
Shaft
|
|
