现代零件查询HDF50/70-7 HYDRAULIC PUMP(NEW)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
245 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| N . |
31FQ-01300
|
[1] |
HYD PUMP-TANDEM
|
|
| N . |
31FQ-01300
|
[1] |
HYD PUMP-TANDEM
|
|
| 1. |
YUAJ-00002
|
[1] |
FRONT COVER KIT
|
|
| 2. |
YUAJ-00003
|
[1] |
DRIVEN GEAR
|
|
| N3. |
YUAJ-00004
|
[1] |
DRIVE GEAR
|
|
| N4. |
YUAJ-00005
|
[4] |
DU BUSHING
|
|
| N5. |
YUAJ-00006
|
[2] |
WEAR PLATE
|
|
| 6. |
YUAJ-00007
|
[2] |
RETAINER SEAL
|
|
| 7. |
YUAJ-00008
|
[2] |
E RING
|
|
| 8. |
YUAJ-00009
|
[1] |
O RING
|
|
| 9. |
YUAJ-00009
|
[1] |
O RING
|
|
| 10. |
YUAJ-00011
|
[1] |
RETAINING RING
|
|
| 11. |
YUAJ-00012
|
[1] |
CENTER SECTION
|
|
| 12. |
YUAJ-00013
|
[1] |
PORT SECTION
|
|
| 13. |
YUAJ-00014
|
[1] |
REAR COVER
|
|
| 14. |
YUAJ-00015
|
[1] |
COUPLING KIT
|
|
| 15. |
YUAJ-00016
|
[1] |
DRIVE SHAFT
|
|
| 16. |
YUAJ-00017
|
[2] |
GEAR
|
|
| 17. |
YUAJ-00018
|
[1] |
DRIVEN SHAFT
|
|
| 18. |
YUAJ-00019
|
[1] |
KEY
|
|
| 19. |
YUAJ-00020
|
[4] |
NEEDLE BEARING
|
|
| N20. |
YUAJ-00021
|
[1] |
INNER SHAFT SEAL
|
|
| N21. |
YUAJ-00022
|
[1] |
OUTER SHAFT SEAL
|
|
| N22. |
YUAJ-00023
|
[1] |
O RING
|
|
| 23. |
YUAJ-00024
|
[1] |
DRIVE PIN
|
|
| 24. |
YUAJ-00025
|
[2] |
SHEAR PIN
|
|
| N25. |
YUAJ-00026
|
[4] |
SNAP RING
|
|
| 26. |
YUAJ-00027
|
[1] |
PLUG
|
|
| N27. |
YUAJ-00028
|
[2] |
DRIVE SCREW
|
|
| N28. |
YUAJ-00029
|
[1] |
NAME PLATE
|
|
| 29. |
YUAJ-00030
|
[4] |
SOCKET BOLT
|
|
| N30. |
YUAJ-00031
|
[8] |
NUT
|
|
| N31. |
YUAJ-00032
|
[8] |
STUD BOLT
|
|
| N32. |
YUAJ-00033
|
[8] |
LOCK WASHER
|
|
