| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 50. | F056009 | [1] | Rod | |
| 51. | ........ | [1] | Nut | SEE PAGE 4440-12 |
| 52. | F013913 | [1] | O-Ring | |
| 53. | F056007 | [1] | Hydraulic Cylinder Barrel | |
| 54. | F057434 | [1] | Seal | |
| 55. | F056005 | [1] | Flange | |
| 59. | ........ | [1] | Pump | SEE PAGE 4440-12 |
| 61. | F056050 | [4] | Screw | |
| 71. | F011293 | [1] | Plug | |
| 72. | F062033 | [1] | Check Valve | |
| 73. | F434971 | [1] | Guide | |
| 74. | F057429 | [1] | Spring | |
| 75. | ........ | [4] | Cap Screw | SEE PAGE 4440-14 |
| 76. | F056037 | [AR] | Seal Kit |
