现代零件查询HDF50/70-7 TURBO CHARGEREPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
237 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
TURBOCHARGER
|
|
| 1. |
28200-45G00
|
[1] |
TURBOCHARGER ASSY
|
|
| 2. |
28251-45G00
|
[1] |
GASKET-T/C
|
|
| 3. |
28223-45C00
|
[1] |
PIPE-T/C TO IN-MANI
|
|
| 4. |
27851-5E100
|
[1] |
HOSE
|
|
| 5. |
28255-42850
|
[1] |
GASKET(B)
|
|
| 6. |
28304-72800
|
[2] |
CLAMP
|
|
| 7. |
11404-10251
|
[3] |
BOLT-HEX
|
|
| 8. |
10225-10004
|
[4] |
NUT-SELF LOCK
|
|
| 9. |
11403-08803
|
[2] |
BOLT
|
|
| 10. |
11403-08251
|
[2] |
BOLT
|
|
| 11. |
28310-45C00
|
[1] |
INLET MANIFOLD ASSY
|
|
| 12. |
11545-06301
|
[2] |
STUD
|
|
| 13. |
28413-45501
|
[1] |
HANGER-PLATE
|
|
| 14. |
43215-69000
|
[2] |
BOLT-FLANGE
|
|
| 15. |
36716-41001
|
[1] |
GASKET
|
|
| 16. |
28315-45510
|
[1] |
GASKET-INLET MAN FR
|
|
| 17. |
11403-08201
|
[8] |
BOLT-FLANGE
|
|
| 18. |
36860-72010
|
[1] |
HEATER RELAY
|
|
| 19. |
36861-41C00
|
[1] |
PLATE-HEATER RELAY
|
|
| 20. |
11290-06121
|
[1] |
BOLT
|
|
