久保田零件查询K12302 TOP LINK BRACKET [AU] [NZ] TOP LINK/TOP LINK BRACKET/PTO PROTECTOREPC Kubota online
广数供应链运营团队, 15 02月, 2025，浏览：
248 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 010. |
K256121070
|
[1] |
SUPPORT REAR LH
|
0.0000(lbs); 0.000
|
| 020. |
K256121080
|
[1] |
SUPPORT REAR RH
|
0.0000(lbs); 0.000
|
| 030. |
0105351225
|
[2] |
BOLT
|
0.0792(lbs); 0.036
|
| 030. |
0112351225
|
[2] |
BOLT
|
0.0880(lbs); 0.040
|
| 050. |
K256139110
|
[1] |
BRACKET FENDER LH
|
25.3000(lbs); 11.500
|
| 050. |
K256139010
|
[1] |
BRACKET FENDER LH
|
27.9400(lbs); 12.700
|
| 060. |
K256139020
|
[1] |
BRACKET FENDER RH
|
24.1340(lbs); 10.970
|
| 070. |
K256139180
|
[1] |
PLATE HITCH
|
5.4120(lbs); 2.460
|
| 080. |
0107351440
|
[14] |
BOLT
|
0.1518(lbs); 0.069
|
| 080. |
0113351440
|
[14] |
BOLT
|
0.1540(lbs); 0.070
|
| 100. |
0207450140
|
[6] |
NUT
|
0.0462(lbs); 0.021
|
| 100. |
0217450140
|
[6] |
NUT
|
0.0308(lbs); 0.014
|
| 110. |
K256139130
|
[1] |
STAY FENDER CENTER
|
16.4560(lbs); 7.480
|
| 120. |
0107351435
|
[4] |
BOLT
|
0.1386(lbs); 0.063
|
| 120. |
0113351435
|
[4] |
BOLT
|
0.1320(lbs); 0.060
|
| 130. |
0107351440
|
[2] |
BOLT
|
0.1518(lbs); 0.069
|
| 130. |
0113351440
|
[2] |
BOLT
|
0.1540(lbs); 0.070
|
| 150. |
0207450140
|
[4] |
NUT
|
0.0462(lbs); 0.021
|
| 150. |
0217450140
|
[4] |
NUT
|
0.0308(lbs); 0.014
|
| 160. |
K256139210
|
[2] |
SCREW SET
|
0.0044(lbs); 0.002
|
| 170. |
K256139220
|
[2] |
SHIM
|
0.0110(lbs); 0.005
|
| 170. |
K256139230
|
[2] |
SHIM
|
0.0132(lbs); 0.006
|
| 170. |
K256139240
|
[2] |
SHIM
|
0.0176(lbs); 0.008
|
